Allied Telesis AT-IE048-480-20 uninterruptible power supply (UPS) 480 W
480W @48Vdc, Industrial AC/DC power supply, DIN rail mount
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The ruggedized IE048-480 industrial power supply is a functional accessory for Allied Telesis products to build a solution suitable for Smart Cities (e.g. Surveillance & Security), Industrial Ethernet, Transportation or any application requiring systems that function in harsh environment with extended operating temperature.
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electromagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
Additional information
| Weight | 1.36 lbs |
|---|---|
| Output power | 480 W |
| Input frequency | 50/60 Hz |
| Product colour | White |
| Operating temperature (T-T) | -20 – 70 °C |
| Storage temperature (T-T) | -40 – 85 °C |
| Operating relative humidity (H-H) | 20 – 90% |
| Storage relative humidity (H-H) | 20 – 90% |
| Weight | 1.2 kg |
| Harmonized System (HS) code | 8504.40.8500 |
| Nominal input voltage | 90 – 264; 98 – 350 V |
| Input operation voltage (min) | 90 V |
| Input operation voltage (max) | 350 V |
| Maximum current | 15 A |
| Form factor | Tower |
| Compliance certificates | RoHS, WEEE |
| Width | 70 mm |
| Depth | 117 mm |
| Height | 124 mm |
| Output operation voltage (max) | 48 V |
| Efficiency | 94% |
| LED indicators | Alarm, Status |
| Nominal output voltage | 48 V |
| Power protection features | Over current, Over voltage, Overheating |
| Cooling type | Active |
| Power factor | 0.98 |
| Housing material | Metal |
| Export Control Classification Number (ECCN) | 5A992C |
