D-Link 5km Long Range Wireless AC Bridge

In Stock

5 km Long Range Wireless AC Bridges DAP-3711

  • We give you a dedicated account manager with every order.
  • We welcome single and bulk orders. Get fast delivery each time.
  • We can offer installation and configuration on orders.
  • We care, get great pricing and great customer service.
  • Any further questions, get in touch on 01933 837600.
SKU: DAP-3711
Brand:

Description

Highlights
The DAP-3711 is the essential solution in providing connectivity to previously believed impossible-to-reach areas. Industry leading core technologies, especially designed for long distance coverage, bring high-speed connectivity to rural areas and challenging terrain equivalent to that of a wired connection.

TDMA Technology Cuts Through the Chatter, Creating Even Stabler Coverage
The DAP-3711 transmission capability is augmented thanks to its integrated Time Division Multiple Access (TDMA). Everything works more efficiently on a schedule, and the DAP-3711 is no different: TDMA creates a schedule for multiple connected clients to work to. Senders and receivers get their own time slot for transmissions. This eliminates hidden node data collisions, in turn maximizing airtime efficiency, significantly cutting down interference and making for a highly scalable solution.

Form Without Sacrificing Function
It can be hard to look good while still being functional. Yet the DAP-3711 strikes the balance just right. The smooth case in crisp white makes for a low-key form that can effortlessly fit any outdoor setting without drawing attention.

Being as functional as it is well-formed, it champions an IP66 rating, fighting dust and repelling water, all while maintaining its unassuming looks.

Cutting Edge Hardware Makes the Previously Impossible, Possible
The DAP-3711 features state-of-the-art hardware, including a high-gain 15 dBi directional antennas. This powerful antenna effortlessly extends high-speed coverage to distances of up to 5 km away.

Discreet Deployment that’s Hassle-Free with Power Over Ethernet (PoE)
Power sockets can be tricky to come by, especially in outdoor deployments. But PoE makes for easy installation and a simple, clean setup. No need to run extra power lines, no added hassle when configuring your hardwiring, and no more cable clutter.

Additional information

Weight 0.88 lbs
Maximum data transfer rate

867 Mbit/s

Maximum transfer distance

5000 m

Antenna design

Internal

Antenna gain level (max)

15 dBi

Wi-Fi

Yes

WLAN data transfer rate (max)

867 Mbit/s

Frequency band

5.180 – 5.825 GHz

Ethernet LAN

Yes

Ethernet LAN interface type

Gigabit Ethernet

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n

Cabling technology

10/100/1000Base-T(X)

Ethernet LAN (RJ-45) ports

2

Web-based management

Yes

Product type

Network bridge

Mounting type

Pole

Product colour

White

LED indicators

LAN, Power, Signal strength, WLAN

Reset button

Yes

International Protection (IP) code

IP66

Power source type

PoE

Power over Ethernet (PoE)

Yes

Power over Ethernet (PoE) voltage

24 V

Operating temperature (T-T)

-40 – 65 °C

Operating relative humidity (H-H)

0 – 90%

Storage temperature (T-T)

-40 – 85 °C

Storage relative humidity (H-H)

0 – 90%

Certification

CE, FCC

Width

288 mm

Depth

45 mm

Height

88 mm

Wi-Fi band

Single-band (5 GHz)

Signal strength

27 dBm

Channels quantity

2 channels

Ethernet LAN data rates

100,1000 Mbit/s

Connectivity technology

Wired & Wireless

Security algorithms

128-bit AES

MAC address filtering

Yes

Material

Acrylonitrile butadiene styrene (ABS)

Surge protection

Yes

Power consumption (typical)

15 W

Weight

600 g

Quantity per pack

1 pc(s)

Harmonized System (HS) code

85176990

Wireless Distribution System (WDS) bridge

Yes
