D-Link DBA-2520P wireless access point 1900 Mbit/s White Power over Ethernet (PoE)

In Stock

DBA-2520P, 1.9 Gbps, 2.4/5 GHz, PoE, 224.5×223.85×50 mm

  • Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
  • Including shipping costs, sent by integratedtechltd.com
  • Pick up at a integratedtechltd.com collection point is possible
  • 30 days to change your mind and free returns
  • Great customer service
SKU: DBA-2520P
Brand:

Description

Cloud Networking, Refreshed
The DBA-2520P Access Point (AP) is part of the Nuclias Cloud solution – D-Link’s complete Cloud-Managed Networking solution for Small-to-Medium Businesses (SMBs), designed to make the ownership and administration of IT infrastructure as simple and hassle-free as possible.

Built for Heavy Workloads
The DBA-2520P delivers high-speed wireless AC (Wave 2) connection reliably, with maximum wireless signal rates of up to 1.9Gbps, and 3 x 3 MIMO (three spatial streams). Performance is further optimized via the Nuclias Cloud platform which adjusts the DBA-2520P’s channel selection, transmission power, and maximum number of client connections.

Advanced Management & Security
The Nuclias Cloud interface gives lets admins easily manage Layer-2 features, such as VLANs and Spanning Tree Protocol (STP). With SSID isolation, MAC address filtering, and end-to-end encryption, this is a versatile solution for those seeking easy configuration, without added complexities.

Full PoE Support
The DBA-2520P Access Point supports Power over Ethernet (IEEE 802.3at standard) for its Gigabit LAN port. Power over Ethernet greatly simplifies the installation of compatible devices such as VoIP phones and IP cameras in remote locations that lack easy access to a power outlet.

Additional information

Weight1.4 lbs
2.4 GHz

Yes

5 GHz

Yes

Maximum data transfer rate

1900 Mbit/s

Maximum data transfer rate (2.4 GHz)

600 Mbit/s

Maximum data transfer rate (5 GHz)

1299 Mbit/s

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

MIMO

Yes

MIMO type

Multi User MIMO

Security algorithms

SSID, WPA, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK

MAC address filtering

Yes

Ethernet LAN (RJ-45) ports

2

Power over Ethernet (PoE)

Yes

Power consumption (max)

19.68 W

Placement

Ceiling, Table, Wall

Product colour

White

Antenna type

Internal

Antenna gain level (max)

4 dBi

Width

224.5 mm

Depth

223.8 mm

Height

50 mm

Quantity per pack

1 pc(s)

Ethernet LAN data rates

10,100,1000 Mbit/s

Number of SSID supported

16

Certification

CE B, FCC B, UL, IC B

Operating relative humidity (H-H)

10 – 90%

Operating temperature (T-T)

0 – 40 °C

Storage temperature (T-T)

-20 – 65 °C

Storage relative humidity (H-H)

5 – 95%

Antennas quantity

2

Weight

811 g

Cable lock slot

Yes

Cable lock slot type

Kensington

Flow control support

Yes

Power consumption (typical)

16.92 W

Antenna direction type

Omni-directional

DHCP server

Yes

Output voltage

12 V

Output current

2.5 A

Harmonized System (HS) code

85176990

Transmitting power

25 dBmW
