Lenovo ThinkSmart Edition Tiny M920q, Intel Core i5-9600T (6C/6T, 2.3/3.9GHz, 9MB), 2x 4GB DDR4-2666, 1x 128GB SSD M.2 2242 PCI
Intel Core i5-9600T (6C/6T, 2.3/3.9GHz, 9MB), 2x 4GB DDR4-2666, 1x 128GB SSD M.2 2242 PCIe 3.0×2 NVMe, Intel UHD Graphics 630, Intel 9560 11ac 2×2 + BT5.0 vPro, Windows 10 IoT Enterprise
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
ThinkSmart Edition Tiny M920q is a purpose-built conference room device—the hardware is designed by Lenovo, and the software is supplied by Zoom or Microsoft.
Additional information
| Weight | 3.16 lbs |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor manufacturer | Intel |
| Processor model | i5-9600T |
| Processor generation | 9th gen Intel® Core™ i5 |
| Processor cores | 6 |
| Processor threads | 6 |
| Processor boost frequency | 3.9 GHz |
| Processor cache | 9 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Internal memory | 8 GB |
| Maximum internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 2 x 4 GB |
| Memory slots | 2x SO-DIMM |
| Total storage capacity | 128 GB |
| Storage media | SSD |
| Total SSDs capacity | 128 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 128 GB |
| SSD interface | PCI Express |
| Card reader integrated | No |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics 630 |
| On-board GPU manufacturer | Intel |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Chassis type | Mini PC |
| Product colour | Black |
| Volume | 1 L |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product type | Mini PC |
| Motherboard chipset | Intel Q370 |
| Audio chip | Realtek ALC233VB2 |
| Audio system | High Definition Audio |
| Trusted Platform Module (TPM) | Yes |
| Number of speakers | 1 |
| Operating system installed | Windows 10 IoT Enterprise |
| Power supply | 135 W |
| Width | 179 mm |
| Sustainability certificates | ENERGY STAR, TCO, EPEAT Gold |
| Depth | 183 mm |
| Height | 34.5 mm |
| Display included | No |
| Processor frequency | 2.3 GHz |
| Number of storage drives installed | 1 |
| HDMI ports quantity | 3 |
| Memory channels | Dual-channel |
| Memory clock speed | 2666 MHz |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Dual Band Wireless-AC 9560 |
| Bluetooth | Yes |
| Antenna type | 2×2 |
| Bluetooth version | 5.0 |
| Weight | 1.32 kg |
| Harmonized System (HS) code | 84715000 |
| Colour name | Black |
| Configurable TDP-down | 25 W |
| Configurable TDP-down frequency | 1.8 GHz |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Intel 64 | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel Clear Video Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Idle States | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Compliance certificates | RoHS |
| Bus type | DMI3 |
| VESA mounting | Yes |
| DVI port | No |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Conflict-Free processor | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
