Lenovo 4XB7A17081 internal solid state drive 240 GB 3.5″ Serial ATA III 3D TLC NAND
ThinkSystem 3.5″ 5300 240GB Entry SATA 6Gb Hot Swap SSD
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The 5300 Entry SATA solid-state drives (SSDs) are new SSDs for ThinkSystem servers. The drives use Micron 96-layer 3D NAND flash memory technology with a SATA 6Gbps interface and provide an affordable solution for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
This product guide provides essential presales information to understand the 5300 Entry SSD offerings, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SSDs and consider their use in IT solutions.
Additional information
| Weight | 0.44 lbs |
|---|---|
| SSD capacity | 240 GB |
| SSD form factor | 3.5" |
| Interface | Serial ATA III |
| Component for | Server/workstation |
| Data transfer rate | 6 Gbit/s |
| NVMe | No |
| Memory type | 3D TLC NAND |
| Read speed | 540 MB/s |
| Write speed | 310 MB/s |
| Mean time between failures (MTBF) | 3000000 h |
| Weight | 70 g |
| Operating temperature (T-T) | 0 – 70 °C |
| Storage temperature (T-T) | -40 – 85 °C |
| Random read (4KB) | 67 IOPS |
| Random write (4KB) | 40 IOPS |
| Read latency | 175 µs |
| Write latency | 300 µs |
| Power consumption (read) | 2.5 W |
| Power consumption (write) | 3 W |
| Compliance certificates | RoHS |
| Harmonized System (HS) code | 84717070 |
| Operating relative humidity (H-H) | 5 – 95% |
| Hardware encryption | Yes |
| Hot-swap | Yes |
| Security algorithms | 256-bit AES |
| Vibration resistance | 3.13 G |
