Lenovo S4620 960 GB 3.5″ Serial ATA III TLC 3D NAND
ThinkSystem 3.5″ S4620 960GB Mixed Use SATA 6Gb HS SSD
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The ThinkSystem S4520 Mixed Use SATA SSDs use 144-layer Intel 3D NAND TLC Flash Memory technology with a 6Gbps SATA interface to provide an affordable solution with industry leading performance.
This product guide provides essential presales information to understand the S4620 SSDs, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about S4620 SSDs and consider their use in IT solutions.
Additional information
| Weight | 0.46 lbs |
|---|---|
| SSD capacity | 960 GB |
| SSD form factor | 3.5" |
| Interface | Serial ATA III |
| Component for | Server |
| Data transfer rate | 6 Gbit/s |
| Memory type | TLC 3D NAND |
| Mean time between failures (MTBF) | 2000000 h |
| Width | 257 mm |
| Depth | 193 mm |
| Height | 95 mm |
| Weight | 484 g |
| Operating temperature (T-T) | 0 – 70 °C |
| Operating vibration | 1000 G |
| Random read (4KB) | 90000 IOPS |
| Random write (4KB) | 54000 IOPS |
| Drive writes per day (DWPD) | 4 |
| Power consumption (write) | 3 W |
| Non-operating vibration | 1000 G |
| Non-operating shock | 3.13 G |
| Certification | FCC Title 47, Part 15B, Class BEN-55035:2017EN-55022:2006EN-55032:2012Low Voltage Directive (LVD) 2014/35/EUEMC Directive 2014/30/EURoHS Directive 2011/65/EUWEEE Directive 2012/19/EUUL 60950-1, 2nd Ed |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Operating shock | 2.17 G |
| Random latency - read (up to) | 103 µs |
| Random latency - write (up to) | 45 µs |
| Sequential latency - read (up to) | 37 µs |
| Sequential latency - write (up to) | 37 µs |
| Storage relative humidity (H-H) | 5 – 95% |
| Endurance rating | 7.1 PB |
