NETGEAR M4250-10G2XF-PoE++ Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
60 Gbps, 8x 1G PoE+ RJ-45, 2x 1G RJ-45, 2x SFP+, 720 W PoE, 440x200x43.2 mm
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Switching engineered for 1G AV over IP with PoE+, Ultra90 PoE++ and rear-facing ports ensuring a clean integration in AV racks. M4250 switches come pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately. For video the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Dante etc. as well as audio/video/control mixed profiles. When multiple switches, NETGEAR IGMP Plus brings automation for you to just connect them together.
M4250 Support for Audio Video Bridging (AVB)
One of the many features designed into the new M4250 product line is full support for Audio Video Bridging (AVB), an industry standard for transporting content over a network. AVB is used most often when very low latency is required such as in live performances when lip sync is critical. All of the AV Line M4250 switches can be optionally licensed for AVB support.
Additional information
| Weight | 5.72 lbs |
|---|---|
| Brand compatibility | 44.64 Mpps |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 10 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x |
| 10G support | No |
| Full duplex | Yes |
| MAC address table | 16000 entries |
| Switching capacity | 60 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 12000 |
| Packet buffer memory | 16 MB |
| Rack mounting | Yes |
| Product colour | Black |
| LED indicators | PoE, Power, Status |
| Mean time between failures (MTBF) | 947871 h |
| Power over Ethernet (PoE) | Yes |
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Operating relative humidity (H-H) | 0 – 90% |
| Storage relative humidity (H-H) | 0 – 95% |
| Width | 440 mm |
| Depth | 200 mm |
| Height | 43.2 mm |
| Weight | 3.83 kg |
| Harmonized System (HS) code | 85176990 |
| Power consumption (typical) | 837.7 W |
| Switch layer | L2/L3 |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| DHCP features | DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| Form factor | 1U |
| Loop protection | Yes |
| Total Power over Ethernet (PoE) budget | 720 W |
| Broadcast storm control | Yes |
| Number of VLANs | 4093 |
| Authentication type | RADIUS |
| Internal memory | 2048 MB |
| Link aggregation | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Latency (1 Gbps) | 1.837 µs |
| Noise level | 66.23 dB |
| Operating altitude | 0 – 3000 m |
| Heat dissipation | 2859.91 BTU/h |
| SFP+ module slots quantity | 2 |
| Rate limiting | Yes |
| SSH/SSL support | Yes |
| BPDU filtering/protection | Yes |
| Authentication | MAC-based authentication |
| Multicast support | Yes |
| Number of queues | 8 |
| Non-operating altitude | 0 – 3000 m |
| Built-in processor | Yes |
| Processor frequency | 1250 MHz |
| IPv4 multicast entries | 2000 |
| IPv6 multicast entries | 2000 |
| Processor model | ARM Cortex-A9 |
