NETGEAR GS110TP Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
GS110TP 8-Port Gigabit PoE+ Ethernet Smart Managed Pro Switch with 2 SFP Ports and Cloud Management
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The NETGEAR GS110TPv3 8-Port Gigabit PoE+ Ethernet Smart Managed Pro Switch comes with 8 PoE copper ports and 2 dedicated SFP ports for fiber uplinks. Cautious spender organizations can now deploy PoE devices with a reasonable PoE power budget of 55W. Each PoE port can provide up to 30 watts to power up the connected devices. Fanless, the GS110TPv3 supports perfectly silent desktop operation or wall mounting. The GS110TPv3 Smart Managed Pro Switch offers an easy-to-use, Web browser-based management GUI with configurable L2 network features like VLANs and PoE operation scheduling, allowing SMB customers to deploy PoE-based VoIP phones and IP surveillance. This switch also comes with NETGEAR Insight Cloud management activation (free for the first two devices) for anytime remote management and monitoring through an intuitive app or Cloud Portal. Advanced features such as IPv4 Layer 2+ static routing including IPv6 management, ACL, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks. The GS110TPv3 features Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings and is backed by NETGEAR’s Lifetime Limited Warranty and 24/7 support including lifetime chat.
Additional information
| Weight | 1.5 lbs |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Full duplex | Yes |
| MAC address auto-learning supported | Yes |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Packet buffer memory | 0.5 MB |
| Rack mounting | No |
| Product colour | Grey |
| LED indicators | Activity, LAN, Link, PoE, Power, Speed |
| Mean time between failures (MTBF) | 1200041 h |
| DC input voltage | 54 V |
| Input current | 1.25 A |
| Power consumption (max) | 15.1 W |
| Power over Ethernet (PoE) | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Operating relative humidity (H-H) | 0 – 95% |
| Storage relative humidity (H-H) | 0 – 95% |
| Width | 236 mm |
| Depth | 101 mm |
| Height | 27 mm |
| Weight | 610 g |
| Manual | Yes |
| Harmonized System (HS) code | 85176990 |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Switch layer | L2/L3/L4 |
| Web-based management | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Flow control support | Yes |
| Spanning tree protocol | Yes |
| DHCP features | DHCP client |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| Power supply included | Yes |
| Package weight | 1.49 kg |
| Certification | CE, FCC, VCCI Class B, C-Tick |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Total Power over Ethernet (PoE) budget | 69.5 W |
| ARP inspection | Yes |
| Port mirroring | Yes |
| Broadcast storm control | Yes |
| Number of VLANs | 64 |
| Access Control List (ACL) IPv6 entries | 100 |
| Memory type | RAM |
| Internal memory | 128 MB |
| Flash memory | 32 MB |
| Power over Ethernet (PoE) power per port | 55 W |
| Link aggregation | Yes |
| Package type | Box |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Operating altitude | 0 – 3000 m |
| Heat dissipation | 237.38 BTU/h |
| Package width | 161 mm |
| Package depth | 267 mm |
| Package height | 86 mm |
| Master (outer) case width | 274 mm |
| Master (outer) case length | 350 mm |
| Master (outer) case height | 309 mm |
| Master (outer) case gross weight | 9.73 kg |
| Products per master (outer) case | 6 pc(s) |
| Switching protocols | SNMP |
| Rate limiting | Yes |
| MAC address filtering | Yes |
| Multicast support | Yes |
| Number of multicast groups filtered | 256 |
| SFP module slots quantity | 2 |
| Security algorithms | 802.1x RADIUS |
| Management protocols | SNMP |
| Supported network protocols | HTTP, HTTPS |
| Non-operating altitude | 0 – 3000 m |
| Processor frequency | 500 MHz |
| IPv4 multicast entries | 32 |
