StarTech.com 1-Port Serial-to-IP Ethernet Device Server – RS232 – DIN Rail and Surface Mountable – Aluminum
StarTech.com 1 Port RS232 to Ethernet IP Converter / Device Server – Aluminum – Serial over IP Device Server – Serial to IP Converter (NETRS2321P)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Connect to, configure and remotely manage an RS-232 serial device over an IP network
This 1-port serial device server is an effective serial-over-IP solution that lets you connect to, configure, and remotely manage an RS232 serial device over a LAN (Local Area Network).
For more control options, the device server is compatible with the free, StarTech.com Serial Device Application Software (NETRSAPP). When coupled with the NETRS2321P, this handy application for iOS, and Android lets you build a custom serial control interface that’s tailored to your specific application.
Access your serial devices remotely
The versatile device server is designed to function seamlessly with your integrated serial ports, while offering baud rates faster than many other device servers (up to 230.4Kbps).The device server provides the tools you need to communicate with remote RS-232 devices as if they were directly connected.
Flexible setup and operation
It offers versatile browser-based or Virtual COM port software configuration for customizing the device to suit your application. Plus, the software communicates directly with the device server, so it can be used in Virtual Machine (VM) environments if you have multiple VMs sharing the same set of hardware.
The device server also offers remote Telnet configuration and support for IP, HTTP, ICMP, DHCP, ARP, TCP and UDP protocols.
Aluminum housing provides durability you can count on
With a sturdy aluminum housing and DIN rail or surface mounting brackets, the serial device server provides a durable remote serial interface for industrial automation, security, Point of Sale and many other applications.
Download the application software and manage your serial devices with ease
Download the StarTech.com serial control software from the Apple App Store, and the Google Play™ Store.
The NETRS2321P is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Additional information
| Weight | 0.43 lbs |
|---|---|
| Serial ports quantity | 1 |
| Serial interface type | RS-232 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Networking standards | IEEE 802.3u |
| Baud rate | 460.8 Kbit/s |
| Data bits | 5, 6, 7, 8 |
| Flow Control type | No, RTS/CTS |
| Parity bit | Even, No, Odd |
| Compliance certificates | RoHS |
| Certification | CE, FCC, TAA, REACH |
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100Base-T(X) |
| Input voltage | 100 – 240 V |
| Output voltage | 12 V |
| Output current | 1.6 A |
| Compatible power plug types | AU, EU, UK, US |
| Supported network protocols | DHCP, TCP/IP, UDP, HTTP, ICMP, ARP, Telnet |
| LED indicators | Activity, Link, Ready |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Weight | 92 g |
| Dimensions (WxDxH) | 53 x 86 x 23 mm |
| Package width | 146 mm |
| Package height | 62 mm |
| Package weight | 416 g |
| Operating temperature (T-T) | 0 – 60 °C |
| Storage temperature (T-T) | -10 – 70 °C |
| Operating relative humidity (H-H) | 0 – 90% |
| Product colour | Black |
| Housing material | Aluminium |
| User guide | Yes |
| AC adapter included | Yes |
| Stop bits | 1, 1.5, 2 |
| Power consumption | 360 mA |
| Power plug type | Type M |
| Link/Act LED | Yes |
| Package length | 17.6 cm |
| Flow control support | Yes |
| RS-232 signals | Rx, Tx |
| Package depth | 176 mm |
| Products per master (outer) case | 25 pc(s) |
| Master (outer) case length | 483 mm |
| Master (outer) case width | 397 mm |
| Master (outer) case height | 307 mm |
