StarTech.com 10GbE Fiber Ethernet Media Converter for 1/2.5/5/10Gbps Network NBASE-T SFP to RJ45 Multigigabit Singlemode/Multim
StarTech.com 10GbE Fiber Ethernet Media Converter for 10Gbps Network 10GBASE-T SFP to RJ45 Multigigabit Singlemode/Multimode Fiber Optic to Copper Network Ethernet to Fiber Bridge (MCM10GSFP)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Fiber to Copper Media Converter | 10GBASE/1000BASE | 10Gbps/1Gbps Unmanaged | Single Mode & Multimode
This Ethernet fiber media converter offers an easy, cost-effective way to extend your network over fiber, using the SFP+ of your choice. It converts a copper RJ45 Ethernet connection to 10Gbps or 1Gbps fiber, to extend your network over longer distances or connect workstations to switches.
Cost-Effective Extensions and Flexible Performance
The RJ45 to fiber media converter provides a cost-efficient way to connect an Ethernet network to remote devices over a fiber backbone. It features an open SFP+ slot that supports the MSA-compliant 10 Gigabit SFP+ or 1 Gigabit SFP that best suits your fiber connection setup (single mode/multimode) and distance requirements.
A Versatile Way to Connect Different Networks
The 10Gb/1Gb fiber media converter supports auto-negotiation while providing versatile connectivity to existing networks and devices, maximizing the usage and performance of legacy equipment.
Network Compatibility:
• 10GBASE-ER
• 10GBASE-LR
• 10GBASE-LW
• 10GBASE-EW
• 10GBASE-R
• 10GBASE-SR
• 10GBASE-SW
• 10GBASE-T
• 1000BASE-T
• 1000BASE-SX
• 1000BASE-LX
Fast and Easy Installation
The unmanaged fiber media converter has a standalone compact design with simple plug-and-play setup to ensure fast and easy installation.
StarTech.com Fiber Media Converters
Overcome the distance limitations of traditional network cables with StarTech.com fiber media converters. Our converters connect different types of network cabling and help you extend networks between buildings and over longer distances. Whether you need to extend a network connection 550 m or 40 km, we can help you.
The StarTech.com Advantage
Additional information
| Weight | 0.5 lbs |
|---|---|
| Maximum data transfer rate | 10000 Mbit/s |
| Networking standards | IEEE 802.1Q, IEEE 802.3ae, IEEE 802.3an |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000,1200,2500,5000,10000 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Fiber mode structure | Multi-mode, Single-mode |
| Internal | No |
| LED indicators | Link, Power |
| Product colour | Black |
| Fiber optic connector | SFP+ |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Width | 80 mm |
| Depth | 122 mm |
| Height | 30 mm |
| Operating temperature (T-T) | 0 – 70 °C |
| Storage temperature (T-T) | -40 – 120 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| Manual | Yes |
| Compliance certificates | RoHS |
| Harmonized System (HS) code | 85176990 |
| Weight | 274 g |
| Package width | 144 mm |
| Package depth | 207 mm |
| Package height | 38 mm |
| Package weight | 350 g |
| Auto-negotiation | Yes |
| Housing material | Aluminium |
| Power over Ethernet (PoE) | No |
| Master (outer) case width | 320 mm |
| Master (outer) case length | 550 mm |
| Master (outer) case height | 320 mm |
| Products per master (outer) case | 20 pc(s) |
| AC adapter included | Yes |
| Input current | 250 A |
| Certification | CE, FCC, UL, PSE |
| Output voltage | 5 V |
| Output current | 2 A |
| Fiber ethernet cabling technology | 10GBASE-LR, 10GBASE-SR |
| External power adapter | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Power plug type | Type M |
