StarTech.com 3 Port 2b 1a Low Profile 1394 PCI Express FireWire Card Adapter
StarTech.com 3 Port 2b 1a Low Profile 1394 PCI Express FireWire Card Adapter – PCI Express 1394a – PCIe FireWire 400 Card
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Add 2 native FireWire 800 ports to your low profile/small form factor computer through a PCI Express expansion slot
This 3 Port PCI Express FireWire card comes equipped with a low profile bracket for installation in small form factor PCs, and includes an optional full-size bracket for installation in a standard-sized PC case.
The FireWire card can be installed in a PCIe slot to add two IEEE1394b (FireWire 800 – 9 pin) ports and one IEEE1394a (FireWire 400 – 6 pin) port, providing broad compatibility with a wide range of FireWire devices (e.g. DV camcorders, external hard drives, digital cameras, etc.).
The 2x FireWire 800 and 1x FireWire 400 card features a native (single chip) PCI Express chipset, which provides faster, more reliable and cost-effective performance than expansion cards that utilize a “bridge” chip.
The StarTech.com Advantage
Additional information
| Weight | 0.22 lbs |
|---|---|
| Product colour | Green |
| Operating temperature (T-T) | 0 – 70 °C |
| Storage temperature (T-T) | -20 – 90 °C |
| Weight | 43 g |
| Chipset | Texas Instruments – XIO2213B |
| Plug and Play | Yes |
| Host interface | PCIe |
| Output interface | IEEE 1394/Firewire |
| Data transfer rate (max) | 0.8 Gbit/s |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 11, Windows 11 x64, |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, |
| Compliance certificates | CE, RoHS |
| Depth | 90 mm |
| Expansion card standard | PCIe 1.1 |
| Internal | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2019 |
| Width | 58 mm |
| Height | 20 mm |
| Harmonized System (HS) code | 84733020 |
| Mounting brackets included | Yes |
| Operating relative humidity (H-H) | 0 – 90% |
| Package width | 175 mm |
| Package depth | 144 mm |
| Package height | 32 mm |
| Package weight | 200 g |
| Products per master (outer) case | 28 pc(s) |
| Master (outer) case width | 331 mm |
| Master (outer) case length | 504 mm |
| Master (outer) case height | 237 mm |
| Mean time between failures (MTBF) | 149905 h |
| Hot-swap | Yes |
| Cables included | FireWire |
| Sustainability compliance | Yes |
| Manual | Yes |
| FireWire 400 ports quantity | 1 |
| Firewire (IEEE 1394) ports | 3 |
| FireWire 800 ports quantity | 2 |
