StarTech.com 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet

In Stock

StarTech.com 3 Port PCI Express USB 3.0 Card + Gigabit Ethernet – Fits Standard & Low-Profile PCs – UASP Supported – Optional SATA Power

  • We give you a dedicated account manager with every order.
  • We welcome single and bulk orders. Get fast delivery each time.
  • We can offer installation and configuration on orders.
  • We care, get great pricing and great customer service.
  • Any further questions, get in touch on 01933 837600.
SKU: PEXUSB3S3GE
Brand:

Description

This PCIe USB 3.0 card couples your peripheral and network connections into a single, scalable solution.

By combining three USB 3.0 ports and one RJ45 port onto a single card, you only need a single PCIe slot for installation, which lets you free up space for other add-ons or upgrades and get more out of your desktop or server.

Combo-card convenience and cost-savings
If you have separate cards for your USB and network connections, this versatile card overcomes the aggravation of running out of PCIe slots while helping to reduce clutter inside your PC.

This dual-purpose card is perfect for building or upgrading your computer. It helps you save money by avoiding the additional costs of purchasing separate USB 3.0 and Gigabit Ethernet adapters.

Flexible install options and legacy device support
You can rest assured this card will fit in your small form-factor system, if needed. It features a dual-profile design that makes it easy to install in either standard or low-profile cases.

The combo card makes it easy to connect peripherals such as your external hard drives or mobile devices. Plus, it’s backward compatible with USB 2.0 and 1.x, so you won’t have to replace all of your existing USB devices.

Gigabit connectivity and network management
Functioning as a network adapter, the card delivers wired network access in locations where Wi-Fi® is unavailable or unreliable.

Support for advanced features such as jumbo frames and VLAN tagging means you can optimize network traffic as needed.

Effective USB 3.0 performance enhanced by UASP
This high-performance SuperSpeed USB 3.0 adapter card supports data transfer rates up to 5 Gbps and is enhanced with UASP support, which can perform ~70% faster read speed and 40% faster write speed over traditional USB 3.0, when paired with a UASP-enabled enclosure.

The PEXUSB3S3GE is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Additional information

Weight 0.14 lbs
Connectivity technology

Wired

Host interface

PCI Express

Interface

Ethernet

Ethernet LAN (RJ-45) ports

1

Internal

Yes

Product colour

Metallic, Red

Windows operating systems supported

Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Window

Width

18 mm

Depth

77 mm

Height

120 mm

Weight

60 g

Quantity per pack

1 pc(s)

PCI version

2.0

Maximum data transfer rate

5000 Mbit/s

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

Harmonized System (HS) code

85176990

Operating temperature (T-T)

5 – 50 °C

Storage temperature (T-T)

-25 – 70 °C

Operating relative humidity (H-H)

20 – 80%

Linux operating systems supported

Yes

Server operating systems supported

Windows Server 2008 R2, Windows Server 2012

Mounting brackets included

Yes

Networking standards

IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x

Cabling technology

10/100/1000BaseT(X)

Wake-on-LAN ready

Yes

Jumbo frames support

Yes

Auto-negotiation

Yes

Jumbo frames

9000

Chipset

Renesas / NEC – µPD720201, Realtek – RTL8153

LED indicators

Activity, Link

Package width

144 mm

Package depth

176 mm

Package height

33 mm

Package weight

150 g

Compliance certificates

RoHS

Certification

CE, FCC

Auto MDIX IEEE

Yes

Manual

Yes

USB version

3.2 Gen 1 (3.1 Gen 1)

Full duplex

Yes

Flow control support

Yes

VLAN tagging

Yes

PCI Card form factor

Full-height (low-profile)

Mean time between failures (MTBF)

1920042 h

Drivers included

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity

3

USB data transfer rates

5000 Mbit/s

UASP support

Yes
