StarTech.com 4-Bay USB 3.0 to SATA Hard Drive Docking Station, USB Hard Drive Dock, External 2.5/3.5″ SATA III SSD/HDD Docking
StarTech.com 4-Bay USB 3.0 to SATA Hard Drive Docking Station, USB Hard Drive Dock, External 2.5/3.5″ SATA III SSD/HDD Docking Station, Hot-Swap Hard Drive Bay, Top-Loading (SDOCK4U33)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
External SSD/HDD Docking Station | USB 3.2 Gen 1 (5 Gbps) to SATA I/II/III
Our SDOCK4U33 Quad-Bay USB 3.0 to SATA Hard Drive Docking Station enables access to up to four 2.5/3.5″ SATA drives from your desktop or laptop computer over USB 3.2 Gen 1 (5 Gbps) .
Each drive loads directly into a tray-less top slot, no additional enclosures or tools are required. This dock enables quick access to drives file transfers, troubleshooting purposes, or system configuration/deployment – ideal for technicians and IT professionals.
This hard drive dock features independently powered SATA controllers. These controllers enable the hot-swapping of idle drives, without impacting the function of active drives, saving you time and resources. Two adjustable 40mm cooling fans keep your drives operating at optimal temperatures for performance and reliability.
Extend the compatibility of this HDD/SDD docking station with the addition of our SATA to IDE Hard Drive Adapter (SAT2IDEADP), for easy docking of legacy 2.5 or 3.5in. IDE hard drives.
Compatible with Any Capacity or File Format
Compatible with 2.5″ and/or 3.5″ SATA HDDs and SSDs of any capacity and file format recognized by your host system. This dock works with any Operating System. Drivers and software are not required.
SDOCK4U33 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Additional information
| Weight | 2.4 lbs |
|---|---|
| Storage media type | HDD, SSD |
| Storage drive interface | Serial ATA, Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5" |
| Number of storage drives supported | 4 |
| Maximum storage capacity | 8 TB |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| Product colour | Black |
| Material | Plastic |
| Maximum data transfer rate | 6 Gbit/s |
| LED indicators | Activity, Power |
| UASP support | Yes |
| Built-in fan | Yes |
| Number of fans | 2 fan(s) |
| Fan diameter | 4 cm |
| AC input voltage | 100-240 V |
| Input current | 2.5 A |
| Output voltage | 12 V |
| Output current | 6.5 A |
| Width | 171.2 mm |
| Depth | 285 mm |
| Height | 85 mm |
| Weight | 1.03 kg |
| Package width | 214 mm |
| Package depth | 341 mm |
| Package height | 170 mm |
| Package weight | 2.18 kg |
| AC adapter included | Yes |
| Cables included | USB |
| Included power plug types | AU, EU, NA, UK |
| Operating temperature (T-T) | 5 – 35 °C |
| Storage temperature (T-T) | -20 – 50 °C |
| Operating relative humidity (H-H) | 20 – 80% |
| Chipset | VL812+ASM1053E |
| Compliance certificates | RoHS |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 361 mm |
| Master (outer) case length | 473 mm |
| Master (outer) case height | 357 mm |
| Products per master (outer) case | 4 pc(s) |
| DC-in jack | Yes |
| Certification | CE, FCC |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Manual | Yes |
| Package dimensions (WxDxH) | 168 x 340 x 213 mm |
| Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1) |
