StarTech.com 4-Port PCIe Gigabit Network Adapter Card
StarTech.com 4 Port PCIe Network Card – Standard Profile – RJ45 Port – Realtek RTL8111G Chipset – Ethernet Network Card – NIC Server Adapter Network Card (ST1000SPEX43)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Add four Gigabit Ethernet ports to a client, server or workstation through one PCI Express slot
Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.
Reliable connectivity to multiple networks
This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111G chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.
A versatile and cost-effective solution
This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).
The ST1000SPEX43 is backed by a StarTech.com 2-year hardware warranty and free lifetime technical support.
The StarTech.com Advantage
– Add four independent Gigabit RJ45 ports to connect to multiple networks for high-bandwidth workstations and servers
– Realtek RTL8111G chipset for reliable performance
– Supports full-duplex flow control
Additional information
Weight | 0.16 lbs |
---|---|
Connectivity technology | Wired |
Host interface | PCI Express |
Interface | Ethernet |
Ethernet LAN (RJ-45) ports | 4 |
Internal | Yes |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro |
Width | 120 mm |
Depth | 138 mm |
Height | 18 mm |
Weight | 95 g |
Maximum data transfer rate | 2000 Mbit/s |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,1000,100 Mbit/s |
Harmonized System (HS) code | 85176990 |
Operating temperature (T-T) | 0 – 55 °C |
Storage temperature (T-T) | -40 – 75 °C |
Operating relative humidity (H-H) | 5 – 95% |
Linux operating systems supported | Yes |
Server operating systems supported | Windows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
Cabling technology | 10/100/1000BaseT(X) |
Wake-on-LAN ready | Yes |
Jumbo frames support | Yes |
Chipset | Realtek RTL8111G |
LED indicators | Activity, Link |
Package width | 209 mm |
Package depth | 145 mm |
Package height | 40 mm |
Package weight | 184 g |
Compliance certificates | CE, RoHS |
Master (outer) case width | 446 mm |
Master (outer) case length | 521 mm |
Master (outer) case height | 344 mm |
Products per master (outer) case | 50 pc(s) |
Auto MDIX IEEE | No |
Full duplex | Yes |
Flow control support | Yes |
Case colour | Yellow |
