StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter
StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter – 2x mSATA SSD to 2.5in SATA Adapter with RAID and 7mm Open Frame Housing
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5″ SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
The StarTech.com Advantage
– Maximize system speed by adding SSD performance
– Achieve greater drive capacity, or secure data redundancy with multiple RAID modes
– Reduce overall power consumption, with high efficiency mSATA SSDs
Additional information
| Weight | 0.11 lbs |
|---|---|
| Product colour | Black, Green |
| Operating temperature (T-T) | -40 – 85 °C |
| Weight | 39 g |
| Chipset | JMicron JMS562 |
| Plug and Play | Yes |
| Host interface | SATA |
| Output interface | mSATA |
| Certification | CE, FCC |
| Data transfer rate (max) | 6 Gbit/s |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Compliance certificates | RoHS |
| Depth | 97 mm |
| Internal | Yes |
| Linux operating systems supported | Yes |
| Width | 70 mm |
| Height | 7 mm |
| Harmonized System (HS) code | 84733020 |
| Mounting brackets included | Yes |
| Quick installation guide | Yes |
| Package width | 174 mm |
| Package depth | 145 mm |
| Package height | 32 mm |
| Package weight | 107 g |
| Port multiplier | Yes |
| Mean time between failures (MTBF) | 5101299 h |
| Hot-swap | No |
| SATA revision | 3.0 |
| RAID levels | 0, 1, BIG, JBOD |
