StarTech.com PCI Express (PCIe) Gigabit Ethernet Multimode SC Fiber Network Card Adapter NIC – 550m
StarTech.com PCI Express (PCIe) Gigabit Ethernet Multimode SC Fiber Network Card Adapter NIC – 550m – PCIe GbE Fiber Optic Network Card
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Connect a PCI Express-based desktop or rackmount PC directly to a Gigabit multimode SC fiber optic network
The PEX1000MMSC2 PCIe Gigabit Fiber Network Card lets you connect a desktop PC directly to a fiber optic network, by adding a multimode SC fiber port to your computer or server through an available PCI Express slot.
Perfect for integrating into new or existing fiber infrastructure over great distances, this card delivers full Gigabit bandwidth to your computer up to 550 meters away from your network source, using multimode 50/125 micron duplex SC fiber cable. Plus, for a wider spectrum of compatibility, this versatile card offers fiber integration with a computer up to 220 meters away when deployed to network frameworks consisting of multimode 62.5/125 micron cabling.
With fiber connectivity, your network is not susceptible to electronic interference, which can be problematic with standard RJ45 copper networks, making this fiber card ideal for secure network setups.
Plus, the card is equipped with a standard profile bracket and includes a low-profile/half-height bracket, making it easy to install in small form-factor computers or 1U server and rackmount applications.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
– Fiber network infrastructure is reliable and secure, with no electromagnetic interference and less data corruption, through a direct fiber-to-desktop connection
– Fits into full or low-profile/small form factor (SFF) systems, with a dual profile design
Additional information
| Weight | 0.2 lbs |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Ethernet / Fiber |
| Internal | Yes |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, |
| Width | 118 mm |
| Depth | 120 mm |
| Height | 18 mm |
| Weight | 66 g |
| Maximum data transfer rate | 2000 Mbit/s |
| LAN controller | Realtek RTL8168E |
| Component for | PC |
| Harmonized System (HS) code | 85176990 |
| Operating temperature (T-T) | 0 – 45 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
| Fiber optic connector | SC |
| Networking standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3z |
| Wake-on-LAN ready | Yes |
| Jumbo frames support | Yes |
| Chipset | RTL8168E |
| LED indicators | Activity, Link |
| Package width | 171 mm |
| Package depth | 218 mm |
| Package height | 49 mm |
| Package weight | 208 g |
| Compliance certificates | RoHS |
| Mac operating systems supported | Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Manual | Yes |
| Full duplex | Yes |
| Maximum operating distance | 550 m |
| Fiber ethernet cabling technology | 1000BASE‑SX |
| Buffer size | 48 KB |
| Power supply | 3.2 W |
