StarTech.com Single Bay USB 3.0 to SATA Hard Drive Docking Station, USB 3.0 (5 Gbps) Hard Drive Dock, External 2.5/3.5″ SATA I/
StarTech.com Single Bay USB 3.0 to SATA Hard Drive Docking Station, USB 3.0 (5 Gbps) Hard Drive Dock, External 2.5/3.5″ SATA I/II/III HDD/SSD Docking Station, Top-Loading Hard Drive Bay (SATDOCKU3S)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
SATA Hard Drive Docking Station, USB 3.0 (5 Gbps) Hard Drive Dock
The SATDOCKU3S USB 3.0 Hard Drive Docking Station delivers full, instant access to any 2.5in or 3.5in SATA (SATA, SATA II, SATA III) hard drive (HDD) or solid state drive (SSD), without having to mount the drive in a computer or install it in an external enclosure. Large capacity drives (tested with up to 4TB 3.5″ and 1TB 2.5″ drives) can be used to greatly enhance your computer’s storage/backup capabilities.
Connected to the host computer through a single USB 3.0 SuperSpeed or USB 2.0 connection, the hard drive docking station provides a convenient, plug-and-play storage solution that delivers instant access to the hard drive without requiring a reboot.
Relying on the outstanding data throughput support of USB 3.0, the HDD docking station is capable of transfer speeds of up to 5Gbps, making it the fastest way to access data from an external drive. Double the value of this hard drive docking station, using a SATA to IDE hard drive adapter (SAT2IDEADP), which enables you to use any 2.5 or 3.5in IDE hard drive in a SATA hard drive dock slot.
To ensure compatibility with your computer system, the SATDOCKU3S supports all of the leading operating system platforms, including: Microsoft Windows®, Apple® OSX, Linux, and Google Chrome OS™.
The StarTech.com Advantage
Additional information
| Weight | 0.7 lbs |
|---|---|
| Storage media type | HDD, SSD |
| Storage drive interface | Serial ATA, Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5" |
| Number of storage drives supported | 1 |
| Maximum storage capacity | 4 TB |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| Product colour | Black |
| Material | Plastic |
| Maximum data transfer rate | 5 Gbit/s |
| Hot-swap | Yes |
| Plug and Play | Yes |
| LED indicators | Activity, Power |
| UASP support | No |
| Built-in fan | No |
| AC input voltage | 110-240 V |
| Output voltage | 12 V |
| Output current | 2.5 A |
| Width | 145 mm |
| Depth | 93 mm |
| Height | 65 mm |
| Weight | 400 g |
| Package width | 162 mm |
| Package depth | 172 mm |
| Package height | 91 mm |
| Package weight | 728 g |
| AC adapter included | Yes |
| Cables included | USB |
| Operating temperature (T-T) | 5 – 80 °C |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating relative humidity (H-H) | 8 – 80% |
| Chipset | ASMedia – ASM1053 |
| Compliance certificates | RoHS |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 190 mm |
| Master (outer) case length | 476 mm |
| Master (outer) case height | 386 mm |
| Products per master (outer) case | 10 pc(s) |
| DC-in jack | Yes |
| Certification | CE, FCC |
| Power plug type | Type M |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Manual | Yes |
