Viewsonic CDE6530 Signage Display Digital signage flat panel 165.1 cm (65″) LCD Wi-Fi 450 cd/m² 4K Ultra HD Black Built-in pro
65″ ADS DLED, 4K, 16:9, 450 cd/m², 1200:1, 8 ms, 178/178, 20W, RJ45, HDMI, RS-232, SPDIF, USB, 100-240 VAC, 24/7, VESA, 25.4 kg
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Streamline your presentations, enhance collaboration, and succeed with the ViewSonic CDE6530 digital display. Whether your employees are in office or working remotely, they will enjoy fast and easy ways to communicate thanks to ViewBoard Cast™ screen sharing software and the myViewBoard® Display app that allows up to four participants to connect and share content. For maximum visibility even in rooms with high ambient light, these displays offer stunning 4K Ultra HD resolution, high brightness and a 25% high haze anti-glare screen. What’s more, these all-in-one displays simplify installation and maintenance thanks to a powerful secured embedded platform that delivers smooth content playback without the need for a PC or media player.
Multiple Ways to Connect and Share
Connect wirelessly through your network or directly to the display. Use the ViewBoard Cast™ screen sharing software along with the web-based myViewBoard® Display app to allow up to four participants (on-site and remote) to connect and share their content regardless of what OS platform they are using (Windows, MacOS, Chrome OS, Android, iOS). In addition, AirPlay, Miracast and the optional ViewBoard Cast button all offer wireless and software-less casting options.
AV Control System Interoperability
These displays are Crestron Connected® as well as Extron and AMX certified for seamless integration. Network admins are always in control with the ability to send control signals such as on/off, switch inputs, push firmware and security updates, and get status from the display.
Centralized Device Control Manager
For IT admins, it’s tough managing the hundreds of devices and displays that live on the network. Now with myViewBoard Manager, an easy-to-use web-based application, IT can securely set up, manage and maintain all of the displays from a centralized dashboard.
Reliable 24/7 Operation Rating
Featuring a long lifespan, this professional-grade commercial display is designed for reliable use 24 hours a day, 7 days a week. Ideal in virtually any commercial application and environment, this commercial display delivers peace of mind with its robust and durable design.
Superb and Stunning Picture Quality
With 4K resolution, high brightness and 25% high haze anti-glare glass treatment, these displays deliver bright, clear and sharp images in any indoor environment.
Powerful Secured Embedded Platform
This display can execute several tasks at once while providing smooth content playback without the need for a PC or media player. The embedded SoC provides PC-like performance and power to run apps, while hardened custom Android OS firmware protects the display from viruses and security breaches by preventing unknown sources to be installed on the system.
Flexible Installation
With landscape or portrait mode options, a uniform bezel width, HDMI in and HDMI out for up to 9-screen tiling (ex 1×2, 2×2, 3×2, 4×2, 3×3, 1×9, etc.) without an external HDMI matrix, this display delivers versatile video wall configuration out-of-the-box.
Advanced Multi-Source Capability
Picture in Picture (PiP) and Picture by Picture (PBP) options allow up to two independent sources to run at the same time.
Integrated Content Management System
Enjoy a cloud-based 30-day trial service subscription from ViewSonic’s content management software, powered by Revel Digital platform. This allows you to instantly transfer multimedia from any HTML5 browser-based device to the display no matter where you are. Works with optional ViewSonic Signage Manager CMS (SW-216) for local content push with perpetual license.
Additional information
Weight | 33.25 lbs |
---|---|
Display diagonal | 165.1 cm (65") |
Display technology | LCD |
Display resolution | 3840 x 2160 pixels |
Display brightness | 450 cd/m² |
LED backlighting type | Direct-LED |
Contrast ratio (typical) | 1200:1 |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Panel life | 40000 h |
HDMI ports quantity | 3 |
USB port | Yes |
Ethernet LAN | Yes |
Wi-Fi | Yes |
HDMI version | 2.1 |
HDMI input ports quantity | 2 |
HDMI output ports quantity | 1 |
USB ports quantity | 3 |
USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
USB connector type | Mini-USB A, USB Type-C |
Ethernet LAN (RJ-45) ports | 1 |
RS-232 interface | Yes |
Built-in speaker(s) | Yes |
Number of built-in speakers | 2 |
RMS rated power | 20 W |
Product design | Digital signage flat panel |
Product colour | Black |
Mounting type | Wall |
Purpose | Universal |
Power consumption (typical) | 165 W |
Power consumption (max) | 335 W |
AC input voltage | 100 – 240 V |
AC input frequency | 50 – 60 Hz |
Internal storage capacity | 32 GB |
Operating system installed | Android 11 |
Display width | 1463.3 mm |
Display depth | 81.6 mm |
Display height | 838.3 mm |
Package width | 1620 mm |
Package weight | 33.3 kg |
Remote control included | Yes |
Cables included | AC, HDMI, RS-232, USB Type-C |
Mounting kit | Yes |
HD type | 4K Ultra HD |
Touchscreen | No |
Native aspect ratio | 16:9 |
Native refresh rate | 60 Hz |
DVI port | No |
Placement supported | Indoor |
Orientation | Horizontal/Vertical |
HDCP | Yes |
HDCP version | 2.2 |
Power consumption (standby) | 0.5 W |
Internal memory | 4 GB |
Display weight | 25.4 kg |
Operating temperature (T-T) | 0 – 40 °C |
Screen shape | Flat |
Package depth | 208 mm |
Package height | 942 mm |
Panel type | ADS |
Response time | 8 ms |
VESA mounting | Yes |
Panel mounting interface | 600 x 400 mm |
Operating hours (hours/days) | 24/7 |
Operating relative humidity (H-H) | 20 – 80% |
Contrast ratio (dynamic) | 5000:1 |
Surface hardness | 3H |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
OPS module slot | Yes |
Anti-glare screen | Yes |
Computer system | Yes |
Built-in processor | Yes |
Processor cores | 4 |
On-board graphics card model | ARM Mali-G52 |
Display number of colours | 1.07 billion colours |
Processor frequency | 1.5 GHz |
Certification | cTUus, FCC, Energy Star 8.0, RoHS, Mexico NOM, Mexico Energy |
Haze rate | 25% |
Quick start guide | Yes |
Batteries included | Yes |
OPS slot | 1 |
Bezel width (bottom) | 1.5 cm |
Bezel width (side) | 1.5 cm |
Bezel width (top) | 1.5 cm |
Computer system type | System on Chip (SoC) |
