Viewsonic LDM163-182 Signage Display Digital signage flat panel 4.14 m (163″) LED Wi-Fi 600 cd/m² Black Android 9
163”, LED, 1920×1080, 3600 x 2025 mm, HDMI, RJ45, Wi-Fi, IR
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The ViewSonic® LDM163-182 is an innovative All-in-One Direct View LED display. With a huge 163” screen size, the LDM163-182 is built to impress as a centerpiece in any higher education auditorium or lecture hall, as well as in corporate conference rooms, boardrooms and lobbies. This display boasts immersive and stunning visuals thanks to Full HD resolution that pairs perfectly with an impressive 600-nit high brightness. This ensures content and messages are always easy to see, even in brightly lit environments. A sleek design and innovative detachable control box delivers a 99% screen-to-body ratio, allowing the display to seamlessly blend into any space while keeping the controls conveniently accessible. Plus, a Glue-on-Board (GOB) LED surface treatment delivers an IP54 rating for enhanced protection from collisions, dust and moisture. With seamless installation, 24/7 reliability, and purposefully designed features for high-impact messaging and digital signage applications, this display sets a new standard for visual excellence at an unbeatable value.
Additional information
| Weight | 60.75 lbs |
|---|---|
| Display diagonal | 4.14 m (163") |
| Display technology | LED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 600 cd/m² |
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Contrast ratio (typical) | 6500:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Active display area (W x H) | 3600 x 2025 mm |
| Panel life | 100000 h |
| Horizontal scan range | 31 – 94 kHz |
| Vertical scan range | 56 – 85 Hz |
| HDMI ports quantity | 5 |
| USB port | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| HDMI version | 2.0 |
| HDMI input ports quantity | 4 |
| HDMI output ports quantity | 1 |
| USB ports quantity | 2 |
| USB version | 3.0 |
| USB connector type | USB Type-A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 3 |
| Audio (L/R) out | 2 |
| RS-232 interface | Yes |
| Infrared data port | Yes |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 30 W |
| Product design | Digital signage flat panel |
| Product colour | Black |
| Mounting type | Wall |
| Purpose | Commercial |
| International Protection (IP) code | IP54 |
| Power consumption (typical) | 919 W |
| Input voltage | 100-120 V |
| Power consumption (sleep) | 0.5 W |
| Power consumption (max) | 2642 W |
| AC input voltage | 220 – 240 V |
| AC input frequency | 50 Hz |
| Internal storage capacity | 32 GB |
| Operating system installed | Android 9 |
| Display width | 3612 mm |
| Display depth | 31 mm |
| Display height | 2171 mm |
| Weight (with stand) | 227 kg |
| Package width | 2250 mm |
| Package weight | 361 kg |
| Remote control included | Yes |
| Cables included | IR, LAN (RJ-45), Power |
| Mounting kit | Yes |
| Wall mountable | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
| Package depth | 1000 mm |
| Package height | 1240 mm |
