Zyxel WAX510D 1775 Mbit/s White Power over Ethernet (PoE)

In Stock

WAX510D, Single Pack 802.11ax 2×2, Dual Optimized Antenna, exclude Power Adaptor, EU and UK, Unified AP, ROHS-1 year NCC Pro Pack icense bundled, WIFI 6

  • We give you a dedicated account manager with every order.
  • We welcome single and bulk orders. Get fast delivery each time.
  • We can offer installation and configuration on orders.
  • We care, get great pricing and great customer service.
  • Any further questions, get in touch on 01933 837600.
SKU: WAX510D-EU0101F
Brand:

Description

True WiFi 6
The WAX510D is truly the next generation of wireless (WiFi 6) AP, especially for businesses looking to strike the right balance between performance and budget. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO, which can’t be found in the earlier releases of 802.11ax products. The WAX510D boasts an impressive quad-core processor with 2 network accumulators to guarantee that a smooth and consistently fast service is provided to each client at all times.

Mount wherever you want without compromise

An access point that fits your need
We understand that mounting an access point to the ceiling isn’t always possible due to the challenging environments like warehouses, historical buildings or stylish hotels were the aesthetics of the building are a priority. The WAX510D is equipped with a dual-optimized antenna that is selectable, allowing the access point to be mounted on the wall or on the ceiling without compromising on performance and coverage.

The smartest choice
The WAX510D is not only efficient at delivering impressive high speeds with smooth and consistent delivery to wireless clients, but also it’s efficient on power. The WAX510D can deliver its impressive performance while keeping the consumption of PoE within the PoE+ standard, so that you can enjoy the latest WiFi 6 technology offering without the need to invest in upgrading your traditional switching architecture.

Manage it your way!
As it comes with support for NebulaFlex Pro, Zyxel’s scalable, cloud-based management system, the WAX510D can be managed via NCC (Nebula control Center), on-premises controller or simply operate alone (controller less). You can choose the way that is best suited to your needs.

Additional information

Weight 0.79 lbs
2.4 GHz

Yes

5 GHz

Yes

Maximum data transfer rate

1775 Mbit/s

Maximum data transfer rate (2.4 GHz)

575 Mbit/s

Maximum data transfer rate (5 GHz)

1200 Mbit/s

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

MIMO

Yes

MIMO type

Multi User MIMO

VLAN support

Yes

Security algorithms

WPA, WPA-Enterprise, WPA-PSK

Web-based management

Yes

Power over Ethernet (PoE)

Yes

Input current

1.5 A

Placement

Ceiling, Wall

Product colour

White

Antenna type

Internal

Antenna gain level (max)

6 dBi

Width

180 mm

Depth

180 mm

Height

39 mm

Certification

FCC Part 15BEN 301 489-1EN 301 489-17EN55022EN55024EN61000-3-2/-3EN60601-1-2BSMI CNS13438

Operating relative humidity (H-H)

10 – 90%

Operating temperature (T-T)

0 – 50 °C

Storage temperature (T-T)

-30 – 70 °C

Storage relative humidity (H-H)

10 – 95%

Antennas quantity

2

Weight

453 g

Wi-Fi Multimedia (WMM)/(WME)

Yes

Power consumption (typical)

17 W

Package width

229 mm

Package depth

215 mm

Package height

64 mm

Package weight

770 g

AC input voltage

12 V

Harmonized System (HS) code

85176990
