APC AP7822B power distribution unit (PDU) 16 AC outlet(s) 2U Black
NetShelter Metered Rack PDU, 2U, 1PH, 7.4kW 230V 32A, x12 C13 and x4 C19 outlets, IEC 309 cord
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
APC Metered Rack PDUs offer resilient power distribution and actively measure, display, and log amperage to support real-time monitoring and historical reporting. This PDU remote monitoring and user-defined alarms to help prevent circuit overloads that can cause accidental power loss to critical equipment. The historical reporting enables users to optimize energy use and plan for capacity with confidence. This PDU can operate at up to 60 degrees Celsius and can be accessed, configured, and managed remotely via EcoStruxure IT, Web, SNMP and Command Line Interface. Power is supplied to the PDU at 200-230 volts via IEC 309 plug with a 3.6m (11 ft) cord while power comes out at 230 volts through (36) IEC 320 C13 and (6) IEC 320 C19 outlets. As a Green Premium product, this unit comes with a verified product environment profile, including carbon footprint, scope 3 emissions and end of life instructions.
Additional information
| Weight | 6.78 lbs |
|---|---|
| PDU types | Metered |
| Rack capacity | 2U |
| Mounting | Horizontal/Vertical |
| Product colour | Black |
| AC outlets quantity | 16 AC outlet(s) |
| AC outlet types | C13 coupler, C19 coupler |
| Input connection type | IEC 309 32A 2P+E |
| Output connections | 12 x C134 x C19 |
| Monitoring | Current, Power, Voltage |
| Nominal input voltage | 208-230 V |
| AC input frequency | 50 – 60 Hz |
| Load capacity | 7680 VA |
| Maximum input current per phase | 32 A |
| Maximum total current draw per phase | 32 A |
| Maximum power | 7680 W |
| Certification | C-tick, CE, FCC 15 A, GOST, ICES-003, IRAM, MIC, VDE, VCCI |
| Operating temperature (T-T) | -5 – 45 °C |
| Storage temperature (T-T) | -25 – 65 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Storage relative humidity (H-H) | 5 – 95% |
| Width | 444 mm |
| Depth | 112 mm |
| Height | 88 mm |
| Weight | 3.36 kg |
| Package weight | 5.41 kg |
| Package width | 508 mm |
| Package depth | 368 mm |
| Package height | 140 mm |
| Total carbon footprint (kg of CO2e) | 8952.07 |
| Maximum current | 32 A |
| Type | Single-phase |
| Power plug | IEC309 |
| Cable length | 3.66 m |
| LED indicators | Yes |
| Compliance certificates | RoHS |
| Power protection features | Overload |
| On/off switch | Yes |
