APC NetShelter Rack Automatic Transfer Switch, 2U, 30A, 120V, 2 L5-30P IN, 16 5-20R OUT, 50/60Hz
NetShelter Rack Automatic Transfer Switch, 2U, 30A, 120V, 2 L5-30P IN, 16 5-20R OUT, 50/60Hz
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
APC NetShelter Rack Automatic Transfer Switch (ATS) AP4453A is the Fifth-Generation range of high availability switches offering greater control of your IT equipment from Cloud to Edge. With Industry leading reliability, agility, and manageability the APC NetShelter Rack ATS provides redundant power to single-corded equipment loads in the IT rack. AP4452A is single phase 1U Rack ATS with 20A rated current, 120V rated voltage and 1920VA load capacity. For North America region, the Regulatory Derated Input Current is 24A. It comes with 2 NEMA L5-30P inlet and 10 NEMA 5-20R outlet sockets. This has been upgraded with APC NMC3 and various technical advancements for network port sharing, environmental monitoring and enhanced security. It has 2-years of standard warranty and 5-years of extended warranty for peace of mind and use for years to come. Users can access and configure Rack ATS through secure Web UI, SNMP, CLI and are fully compatible with EcoStruxure IT.
Additional information
| Weight | 9.34 lbs |
|---|---|
| Input operation voltage (min) | 108 V |
| Input operation voltage (max) | 132 V |
| AC input frequency | 50 – 60 Hz |
| Input current | 30 A |
| Form factor | Rackmount |
| Rack capacity | 2U |
| Product colour | Black |
| AC outlets quantity | 16 AC outlet(s) |
| AC outlet types | NEMA L5-20R |
| Operating temperature (T-T) | -5 – 45 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Total carbon footprint (kg of CO2e) | 2108.5233698851 |
| Width | 432 mm |
| Depth | 236 mm |
| Height | 88 mm |
| Weight | 6.33 kg |
| Certification | EN 55022 class A, FCC part 15 class A |
| Storage temperature (T-T) | -25 – 65 °C |
| Display | LCD |
| Country of origin | Philippines |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Compliance certificates | RoHS, REACH, WEEE |
| Packaging recycled materials | Recycled cardboard |
| Mounting | front; rear; horizontal |
| Removable battery | Yes |
| Halogen free | No |
| Sustainable packaging | No |
| Proposition 65 | Yes |
| Customs product code (TARIC) | 8537109899 |
| Preferred mounting position | no preference |
| Take-back system | No |
| Packaging without single use plastic | No |
