ATEN VGA EDID Emulator

ATEN VGA EDID Emulator

In Stock

VGA EDID Emulator

Add to wishlist
  • We give you a dedicated account manager with every order.
  • We welcome single and bulk orders. Get fast delivery each time.
  • We can offer installation and configuration on orders.
  • We care, get great pricing and great customer service.
  • Any further questions, get in touch on 01933 837600.
SKU: 2A-130G
Category:
Brand:

Description

The 2A-130G VGA EDID Emulator is designed for ATEN KVM extender or video extender installations that do not utilize a local monitor at the site where the computer/video source is located. The 2A-130G emulates and stores a default ATEN EDID (Extended Display Identification Information) setting in a non-volatile memory. This means the computer/video source can still “see” the display, even though it is not directly connected.

The 2A-130G is suitable for any ATEN KVM or video extender installation where a monitor is not required at the local site, providing a simple, cost-saving, and convenient solution for display-related boot-up problems.

Additional information

Weight 0.028 lbs
Cable length

0.35 m
Connector 1

USB Type-A
Connector 2

VGA (D-Sub)
Connector 1 gender

Male
Connector 2 gender

Male
Maximum resolution

1920 x 1200 pixels
Maximum refresh rate

60 Hz
Product colour

Blue, Silver
Operating temperature (T-T)

0 – 50 °C
Storage temperature (T-T)

-20 – 60 °C
Operating relative humidity (H-H)

0 – 80%
Connector 1 form factor

Straight
Connector 2 form factor

Straight
Weight

40 g
Package width

205 mm
Package depth

245 mm
Package height

20 mm
Package weight

52 g
Master (outer) case width

212 mm
Master (outer) case length

235 mm
Master (outer) case height

350 mm
Products per master (outer) case

40 pc(s)
Harmonized System (HS) code

84733080
Supported graphics resolutions

1366 x 768, 1920 x 1200 (WUXGA)
Width

34 mm
Depth

65.9 mm
Height

16 mm
Master (outer) case net weight

1.6 kg
Master (outer) case gross weight

2.61 kg
