C2G HDMI over Cat5/6 Extender up to 50 m
HDMI over Cat5/6 Extender – video/audio extender – HDMI
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The HDMI over Cat5/6 extender is ideal for extending digital video and audio over long distances of up to 50 metres (164 feet), making it a great solution for digital signs, schools, churches, trade show presentations or other applications where the HDMI source is more than 15 metres (50 feet) from the display. The extender can also send HDMI signals over existing Cat5 or Cat6 cable infrastructure for cost-effective reliability, while maintaining high-performance quality and video resolutions of up to 1080p at 60Hz. With no drivers or software to install, the HDMI over Cat5/6 Extender provides total plug and play convenience. Simply connect the transmitter to the video source, the receiver to the display, and extend with a single category cable for quality video and audio.
Additional information
| Weight | 0.64 lbs |
|---|---|
| Type | AV transmitter |
| Cable types supported | Cat5, Cat6 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 0 – 80% |
| Compliance certificates | RoHS |
| Input current | 0.5 A |
| AC input voltage | 100 – 240 V |
| Dimensions (WxDxH) | 49 x 84.5 x 24 mm |
| Weight | 480 g |
| Supported video modes | 1080p |
| Bandwidth | 6.75 Gbit/s |
| HDMI in | 1 |
| Cable length | 1.5 m |
| Number of HDMI outputs | 1 |
| AC input frequency | 50 – 60 Hz |
| Output current | 1 A |
| Storage relative humidity (H-H) | 0 – 80% |
| Operating voltage (transmitter) | 5 V |
| 3D | Yes |
