Epson WorkForce DS-570W Power PDF
A4, Sheetfed, 600 x 600DPI, 24Bits, ReadyScan LED, Duplex, Wi-Fi, NFC, USB 3.0
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Wireless business scanner
With powerful media handling and innovative smart features to ensure a high level of data integrity, the wireless WorkForce DS-570W is geared towards highly-efficient and simple integration into an organisation’s workflow. A 50-page ADF, fast scan speeds of up to 35ppm/70ipm, along with Wi-Fi , NFC and USB 3.0 connectivity, enable you to rapidly connect, capture, edit, store and share business documents.
Intelligent features improve efficiency, accuracy and data reliability
With an industry-first slow mode{s1 for scanning crumpled or fragile documents, the ability to scan challenging media has never been easier. The Active Separation Roller System prevents tedious document double feeds and the Double Feed Detection Skip (DFDS) means you can scan difficult media like envelopes or documents with post-it notes. Auto Scan Mode enables the processing of a vast number of documents as one file.
Highly versatile
Single-pass double-sided scanning ensures rapid document processing, while it’s possible to scan a versatile array of media such as paper as thin as 27gsm, or thick card at 413gsm. The instantly-recognised A3 carrier sheet automatically stitches larger documents back together digitally.
Flexible connectivity
Scan documents easily to mobile, tablet and Wi-Fi-enabled work stations with its wireless capability. Built-in NFC enables instant Wi-Fi connectivity. It has high-speed USB 3.0 with TWAIN and WIA drivers for enhanced compatibility with Document Management Systems.
Image enhancement and document management software
Epson Scan 2.0 software makes it easy to edit images with features such as de-skew and auto rotate, while Document Capture Pro{s3 is the easy to use solution for capturing and storing electronic documents at the touch of a button.
Additional information
| Weight | 4.64 lbs |
|---|---|
| Optical scanning resolution | 600 x 600 DPI |
| Duplex scanning | Yes |
| ADF scan speed (b/w, A4) | 35 ppm |
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | White |
| Display | LCD |
| Sensor type | CIS |
| Daily duty cycle (max) | 4000 pages |
| Scan to | E-mail, FTP, Network folder, Print |
| Auto document feeder (ADF) input capacity | 50 sheets |
| Maximum ISO A-series paper size | A4 |
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Wi-Fi | Yes |
| Ethernet LAN | No |
| Power supply type | AC |
| Width | 296 mm |
| Depth | 169 mm |
| Height | 176 mm |
| Weight | 3.7 kg |
| Operating temperature (T-T) | 5 – 35 °C |
| Operating relative humidity (H-H) | 15 – 80% |
| Maximum scan size | 215.9 x 6096 mm |
| Colour scanning | Yes |
| Light source | ReadyScan LED |
| Scan file formats | PDF, TIFF |
| Scanning media types supported | Business Card, Plastic Card, Post Card(JPN), Thin paper |
| Quantity per pack | 1 pc(s) |
| Scan drivers | TWAIN, WIA |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5, B6 |
| Letter | Yes |
| Legal | Yes |
| Package width | 250 mm |
| Package depth | 366 mm |
| Package height | 290 mm |
| Package weight | 4.72 kg |
| Cables included | AC, USB |
| Windows operating systems supported | Yes |
| Server operating systems supported | Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012 R2 |
| Output colour depth | 24 bit |
| Country of origin | Indonesia |
| ADF scan speed (colour, A4) | 35 ppm |
| Input colour depth | 30 bit |
| Mac operating systems supported | Yes |
| Storage temperature (T-T) | -25 – 60 °C |
| Storage relative humidity (H-H) | 15 – 85% |
| Standard input capacity | 50 sheets |
| Bundled software | Epson Document Capture (Mac only), Epson Document Capture Pro (Windows only), Epson Document Capture Pro Server (on free download), Epson Scan 2, Presto! BizCard 5.6 |
| Auto Document Feeder (ADF) media weight | 27 – 413 g/m² |
| Image formats supported | JPEG, TIFF, MTIFF |
| Products per pallet | 63 pc(s) |
| Products per pallet (UK) | 84 pc(s) |
| Linux operating systems supported | Yes |
| Maximum scan area (ADF) | 50.8 x 50.8 mm |
| Minimum scan area (ADF) | 50.8 x 50.8 mm |
| Box contents | Driver and utilities, Main unit, Power cable, Setup guide, USB cable, Warranty Documents |
| Compatible operating systems | Linux, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Mac OS X 10.6.8, Windows 10, Windows 7, Windows 7 x64, Windows 8, Windows 8 (32/64 bit), Windows 8 RT, Windows 8.1, Windows 8.1 x64 Editio |
| Supported network protocols | TCP/IP, DHCP, DNS, SNMP, SLP |
| Ethernet LAN data rates | 100,10,1000 Mbit/s |
| Optional connectivity | Ethernet |
| Data compression | Hardware JPEG compression, TIFF Compression (JPEG(7) , CITT G4, LZW), PDF Compression |
| IPv6 support | Yes |
| Interface | Wireless LAN IEEE 802.11a/b/g/n, Wi-Fi Direct, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T) (optional), USB 3.0 |
| Printer features | RGB colour dropout, Skip blank page, A3 stitching, Punch holes removal, Advanced editing, Automatic de-skew, Automatic multi-document recognition, RGB colour enhance, Dual Image Output (Windows only), |
| Scanner features | RGB colour dropout, Skip blank page, A3 stitching, Punch holes removal, Advanced editing, Automatic de-skew, Automatic multi-document recognition, RGB colour enhance, Dual Image Output (Windows only), |
| Linear scan speed (metric) | Monochrome:35 pages/min – Color:35 pages/min measured with Size: A4 , Resolution: 200 / 300 dpi, Monochrome:70 image/min – Color:70 image/min measured with Size: A4 , Resolution: 200 / 300 dpi |
