DELL Xeon 5218 processor 2.3 GHz 22 MB Tray
Intel Xeon Gold 5218 (22MB Cache, 2.3GHz, 3.7GHz Turbo)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The Intel Xeon® 5218 2.3GHz Sixteen Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.
Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon 5218 2.3GHz Sixteen Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
Additional information
| Weight | 0.22 lbs |
|---|---|
| Processor family | Intel® Xeon® Gold |
| Processor cores | 16 |
| Processor socket | LGA 3647 (Socket P) |
| Cooler included | No |
| Processor manufacturer | Intel |
| Processor model | 5218 |
| Processor base frequency | 2.3 GHz |
| Processor operating modes | 64-bit |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor threads | 32 |
| Processor boost frequency | 3.9 GHz |
| Processor cache | 22 MB |
| Thermal Design Power (TDP) | 125 W |
| Processor ARK ID | 192444 |
| Memory channels | Hexa-channel |
| Maximum internal memory supported by processor | 1.02 TB |
| Memory types supported by processor | DDR4-SDRAM |
| ECC | Yes |
| On-board graphics card | No |
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Execute Disable Bit | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX-512 |
| Scalability | 4S |
| Embedded options available | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 1 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Tcase | 87 °C |
| Launch date | Q2'19 |
| Status | Launched |
| Number of UPI links | 2 |
| Harmonized System (HS) code | 85423119 |
| Processor package size | 76.0 x 56.5 mm |
| Processor codename | Cascade Lake |
| Intel® Run Sure Technology | Yes |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | No |
| Memory clock speeds supported by processor | 2667 MHz |
| Processor lithography | 14 nm |
| Component for | Server/workstation |
| Memory speed (max) | 2667 MHz |
| Package type | Tray |
| PCI Express CEM revision | 3.0 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel TSX-NI | Yes |
| Compatibility | – PowerEdge R640- PowerEdge R740- PowerEdge R940- PowerEdge R740XD- PowerEdge C6420- PowerEdge R440- PowerEdge T640- PowerEdge FC640- PowerEdge M640- PowerEdge M640 VRTX- PowerEdge R540- PowerEdge C41 |
| Intel Speed Select Technology (SST) | No |
| Intel® Optane™ DC Persistent Memory technology | Yes |
| Product type | Processor |
