Lenovo 4XB7A17098 internal solid state drive 960 GB 3.5″ Serial ATA III TLC 3D NAND
3.5″ 5300 960GB Mainstream SATA 6Gb Hot Swap
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The ThinkSystem 5300 Mainstream SATA 6Gb solid-state drives (SSDs) use Micron NAND flash memory technology with a SATA 6Gbps interface to provide an affordable solution for mixed read/write workloads.
This product guide provides essential presales information to understand the 5300 Mainstream SSD offerings, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SSDs and consider their use in IT solutions.
Additional information
| Weight | 0.44 lbs |
|---|---|
| SSD capacity | 960 GB |
| SSD form factor | 3.5" |
| Interface | Serial ATA III |
| Component for | Server/workstation |
| NVMe | No |
| Memory type | TLC 3D NAND |
| Mean time between failures (MTBF) | 3000000 h |
| Width | 70 mm |
| Depth | 100 mm |
| Height | 7 mm |
| Weight | 70 g |
| Operating temperature (T-T) | 0 – 70 °C |
| Storage temperature (T-T) | -40 – 85 °C |
| Random read (4KB) | 95000 IOPS |
| Random write (4KB) | 75000 IOPS |
| Read latency | 175 µs |
| Write latency | 100 µs |
| S.M.A.R.T. support | Yes |
| Power consumption (read) | 2.8 W |
| Power consumption (write) | 3.4 W |
| Non-operating vibration | 3.13 G |
| Non-operating shock | 1500 G |
| Certification | Micron Green StandardBuilt with sulfur resistant resistorsCE (Europe): EN 55032 Class B, RoHSFCC: CFR Title 47, Part 15 Class BUL: UL-60950-1, 2nd EditionBSMI (Taiwan): approval to CNS 13438RCM (Austr |
| Operating relative humidity (H-H) | 5 – 95% |
| Hardware encryption | No |
| Hot-swap | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Security algorithms | 256-bit AES |
