NETGEAR MS305 Unmanaged 2.5G Ethernet (100/1000/2500) Black
5-Port, 2.5 G, 9.24W, 158 x 101 x 29 mm, 480 g
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The NETGEAR 5-port Multi-Gigabit Unmanaged Switch, MS305, helps businesses cost-effectively expand their networks with multi-gig speeds. The MS305 Multi-Gigabit Ethernet switch comes with five (5) 2.5G ports in a metal case and can be placed on a desk or mounted on a wall with the included wall mount kit. This switch is energy efficient, built to last, and rigorously tested to provide the reliability businesses need. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks.
RELIABLE PERFORMANCE
Superior network performance at non-blocking rate delivers true Multi-Gig speed with no compromise
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
PLUG-AND-PLAY
No software to install. No configuration needed. Zero maintenance required
SILENT OPERATION
The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Install your switch on your desktop, or mount it to your wall with the hardware provided in the box.
Additional information
| Weight | 0.88 lbs |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 9720 |
| Packet buffer memory | 1 MB |
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Mean time between failures (MTBF) | 1401743 h |
| DC input voltage | 12 V |
| Input current | 1 A |
| Power consumption (max) | 9.24 W |
| Power over Ethernet (PoE) | No |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Operating relative humidity (H-H) | 0 – 90% |
| Storage relative humidity (H-H) | 0 – 95% |
| Width | 158 mm |
| Depth | 101 mm |
| Height | 29 mm |
| Weight | 480 g |
| Power consumption (typical) | 4.6 W |
| Number of fans | 0 fan(s) |
| Power source | DC |
| Power supply included | Yes |
| Stackable | No |
| Compliance certificates | CCC, Low Voltage Directive (LVD) |
| Forwarding rate | 3.72 Mpps |
| Wall mountable | Yes |
| Fanless | Yes |
| Half duplex | Yes |
| Head-of-line (HOL) blocking | Yes |
| Cable length detection | Yes |
| Latency (1 Gbps) | 2458 µs |
| Noise level | 0 dB |
| Input voltage | 12 V |
| Operating altitude | 0 – 3000 m |
