NETGEAR MS108EUP Managed L2/L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Grey
40Gbps, 16K MAC, 8x 1/2.5G LAN RJ-45, PoE+, 210x140x40 mm
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Provides 8 ports 1G/2.5G with 4 PoE+ ports and 4 Ultra60 PoE++ ports making it a perfect switch for WiFi 6 AP connectivity, IP surveillance and more.
Multi-Gigabit Ethernet
8 ports provide up to 2.5 Gbps of dedicated, non-blocking bandwidth each.
PoE Support
4 Ultra60 PoE++ and 4 PoE+ ports provide a total of 230W of power so you can power and connect your devices with a single wire.
Advanced PoE Controls
Manage PoE prioritization, scheduling, power limit per port, and more for simple control over all PoE-powered devices.
Non-Blocking Switching
40Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices.
Fanless Design
Silent operation makes this switch perfect for noise-sensitive environments.
Versatile Mounting Options
Install your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box.
Additional information
| Weight | 2.64 lbs |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Full duplex | Yes |
| MAC address table | 16000 entries |
| Switching capacity | 40 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 12000 |
| Packet buffer memory | 1.5 MB |
| Rack mounting | No |
| Product colour | Grey |
| Housing material | Metal |
| LED indicators | Yes |
| Mean time between failures (MTBF) | 373644 h |
| Power over Ethernet (PoE) | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Operating relative humidity (H-H) | 0 – 90% |
| Storage relative humidity (H-H) | 0 – 95% |
| Width | 210 mm |
| Depth | 140 mm |
| Height | 40 mm |
| Weight | 900 g |
| Harmonized System (HS) code | 85176990 |
| Switch layer | L2/L3 |
| Web-based management | Yes |
| Copper ethernet cabling technology | 100BASE-T, 1000BASE-T |
| Flow control support | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN, Tagged VLAN |
| DHCP features | DHCP client |
| IGMP snooping | Yes |
| Power source | PoE |
| Power supply included | Yes |
| Certification | CE <br />FCC 15 B<br />CE/EN55032/24<br />CSA<br />VCCI<br />ACMA<br />KC<br />CCC<br />BSMI |
| Stackable | No |
| Total Power over Ethernet (PoE) budget | 230 W |
| Port mirroring | Yes |
| Number of VLANs | 64 |
| Password protection | Yes |
| Link aggregation | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Operating altitude | 0 – 3000 m |
| Rate limiting | Yes |
| Multicast support | Yes |
| Queue scheduling algorithms | Strict Priority Queue (SPQ), Weighted Round Robin (WRR) |
| Number of multicast groups filtered | 128 |
| Non-operating altitude | 0 – 3000 m |
