Sony BRC-H800 security camera Dome IP security camera Indoor Ceiling

In Stock

20.4 MP, 1.7lux, 12x Zoom, ±170° Pan, -30°-90° Tilt,

  • We give you a dedicated account manager with every order.
  • We welcome single and bulk orders. Get fast delivery each time.
  • We can offer installation and configuration on orders.
  • We care, get great pricing and great customer service.
  • Any further questions, get in touch on 01933 837600.
SKU: BRC-H800
Brand:

Description

Remotely capture broadcast quality Full HD images with smooth, silent PTZ and excellent low-light sensitivity.

The BRC-H800 remote camera combines uncompromising broadcast picture quality and smooth, silent PTZ operation with the flexibility of 3G-SDI and HDMI connections.
Designed for unattended operation, this compact but powerful robotic camera is an ideal complement to other broadcast cameras for capturing images in hard-to-reach or unobtrusive positions. It’s equally at home in TV newsrooms, remote studios and on-air suites, auditoriums, houses of worship, courtrooms or sports stadiums. It’s also particularly suited to efficient multi-camera set-ups, under the control of a single operator.
The 1-inch type Exmor R CMOS image sensor captures crisp, low-noise Full HD images at 60p, with excellent low-light sensitivity. The large image sensor also allows the creation of beautiful ‘bokeh’ effects with a shallow depth of field to suit any artistic intention.
Speedy, near-silent PTZ operation with 12x optical zoom accommodates wide-angle scenes and tightly framed close-ups, with Clear Image Zoom 24x(HD) extending this range even further without visible loss of resolution. Broadcast-friendly features include dual tally lamps for on-air operation, while operational flexibility is enhanced with options for ceiling, table top or tripod mounting. There’s also a broad range of video interfacing and remote control possibilities – plus support for PoE+ and genlock – for smooth integration into any broadcast, professional or corporate AV environment.

Additional information

Weight 7.88 lbs
Type

IP security camera

Placement supported

Indoor

Preset points

Yes

Day/night mode

Yes

Light exposure modes

Aperture priority AE, Auto, Manual

Mounting type

Ceiling

Product colour

Black

Form factor

Dome

Minimum illumination

1.7 lx

Lens viewing angle, horizontal

64.6°

Tilt angle range

-30 – 90°

Tilt speed

60 °/sec

Pan range

-170 – 170°

Pan speed

60 °/sec

White balance

Auto, Indoor, Manual, One push, Outdoor

Camera shutter speed

1/6 s

Sensor type

CMOS

Optical zoom

12x

Focal length range

9.3 – 111.6 mm

Focus

Motorized/Manual

Gain control type

Auto/Manual

Flip & mirror

Yes

Ethernet LAN

Yes

Networking standards

IEEE 802.1Qaz

Ethernet LAN (RJ-45) ports

2

RS-422 ports

1

HDMI ports quantity

2

Remotely operated

Yes

Power source type

PoE

Power consumption (typical)

19 W

Power consumption (Power over Ethernet (PoE))

23 W

Power over Ethernet (PoE)

Yes

Operating temperature (T-T)

0 – 40 °C

Storage temperature (T-T)

-20 – 60 °C

Width

198 mm

Depth

260 mm

Height

238 mm

Weight

4.3 kg

Number of cameras

1

Mounting kit

Yes

Screws included

Yes

Automatic gain control

Yes

Full HD

Yes

Harmonized System (HS) code

85258900

Preset programs quantity

16

Remote control included

Yes
