StarTech.com 1 Port RS232 Serial Ethernet Device Server – PoE Power Over Ethernet
StarTech.com 1 Port RS232 Serial Ethernet Device Server – PoE Power Over Ethernet – Serial over IP Device Server Adapter – PoE-Powered
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Connect to, configure and remotely manage an RS-232 serial device over an IP network
The NETRS2321POE 1 Port RS232 Serial Ethernet Device Server – PoE (Power Over Ethernet) allows you to install your RS232 devices anywhere on your TCP/IP Ethernet WAN/LAN, and access them as if they were right beside you – even over the Internet!
The Serial Device Server is designed to function seamlessly with your other integrated and add-on serial ports as if they were right inside your computer. Perfect for industrial automation, security, Point of Sale, or any long-range serial application, delivering reliable performance in any environment.
The Ethernet/serial device server supports PoE (Power over Ethernet) when connected to a PoE compliant device – eliminating the need for an external power supply and outlet, and making it easier to situate the device server as needed.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
– PoE support gives you the freedom to situate your serial device where it is needed even when no power outlet is available
– IP-based connection to your serial devices allows remote administration from anywhere; even over the Internet
– Remotely connect to multiple NETRS2321POE units with a single PC for simple and efficient management of devices from a single location
Additional information
| Weight | 0.96 lbs |
|---|---|
| Serial ports quantity | 1 |
| Serial interface type | RS-232 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Networking standards | IEEE 802.3af |
| Baud rate | 115.2 Kbit/s |
| Data bits | 6, 7, 8 |
| Compliance certificates | RoHS |
| Certification | CE, FCC, REACH, TAA |
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100Base-T(X) |
| Input voltage | 100 – 240 V |
| Output voltage | 12 V |
| Output current | 0.1 A |
| Compatible power plug types | EU, UK, US |
| Input current | 0.3 A |
| Supported network protocols | UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping |
| LED indicators | Activity, Link |
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Pro |
| Weight | 259 g |
| Dimensions (WxDxH) | 66.3 x 107 x 25 mm |
| Package width | 296 mm |
| Package height | 70 mm |
| Package weight | 963 g |
| Operating temperature (T-T) | 0 – 55 °C |
| Storage temperature (T-T) | -20 – 85 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| User guide | Yes |
| Data transfer rate | 0.1152 Mbit/s |
| Stop bits | 1, 2 |
| Mean time between failures (MTBF) | 233403 h |
| Power consumption | 100 mA |
| Power plug type | Type M |
| Link/Act LED | Yes |
| Package length | 19.2 cm |
| Compatible operating systems | Windows Vista (32), XP (32), 2000 |
