Description
Add 2 external or internal SATA 6 Gbps ports to a computer, through a PCI Express slot
The PEXESAT322I PCI Express SATA III Controller Card (6 Gbps) gives you the option to add 2 internal or external SATA ports to your computer, through a single PCI Express (x1) card slot. The card features on board jumper selection, which enables you to configure the card to provide 2 internal or external SATA III ports, or one of each, as needed.
The SATA III card features Port Multiplier (PM) support on each port, which allows multiple drives to be connected over a single cable when necessary to maximize the number of SATA device connections while reducing the amount of cabling required.
The card is fully compliant with the SATA revision 3.0 specification (up to 6Gbps of data bandwidth), enabling you to utilize the speeds of high performance hard drives and Solid State Drives (SSD), as well as SATA-based optical drives (CD-ROM, DVD-ROM, Blu-Ray).
The PEXESAT322I SATA III Controller card is backed by our 2-year manufacturer warranty and free lifetime technical support.
The StarTech.com Advantage
Additional information
| Weight | 0.15 lbs |
|---|---|
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -20 – 60 °C |
| Weight | 48 g |
| Chipset | ASMedia – ASM1061 |
| Host interface | PCIe |
| Output interface | SATA |
| Certification | CE, FCC, REACH |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Window |
| Compliance certificates | RoHS |
| Depth | 121 mm |
| Internal | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Width | 92 mm |
| Height | 20 mm |
| Quantity | 1 |
| Harmonized System (HS) code | 84733020 |
| Mounting brackets included | Yes |
| Operating relative humidity (H-H) | 5 – 85% |
| Package width | 173 mm |
| Package depth | 144 mm |
| Package height | 30 mm |
| Package weight | 152 g |
| Products per master (outer) case | 80 pc(s) |
| Master (outer) case width | 307 mm |
| Master (outer) case length | 586 mm |
| Master (outer) case height | 360 mm |
| Internal SATA ports quantity | 2 |
| Port multiplier | Yes |
| Cables included | SATA |
| SATA revision | 3.0 |
| Drivers included | Yes |
| Manual | Yes |
| Logical block addressing (LBA) support | 48 bit |
| eSATA ports quantity | 2 |
| Native Command Queuing (NCQ) | Yes |
