StarTech.com 32ft (10m) Active DisplayPort Cable – 4K Ultra HD DisplayPort Cable – Long DP to DP Cable for Projector/Monitor –
StarTech.com 32ft (10m) Active DisplayPort Cable – 4K Ultra HD DisplayPort Cable – Long DP to DP Cable for Projector/Monitor – DP Video/Display Cord – Latching DP Connectors (DISPL10MA)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Connect DisplayPort®-equipped devices up to 10m away with no signal loss
The DISPL10MA 10m Active DisplayPort® Cable features a built-in active signal booster for a connection distance of up to 30 feet (10m) between your DisplayPort-enabled devices – almost double the DisplayPort connection distance limitation of 16ft, with no signal loss.
This durable yet lightweight active DP cable features a thinner 32 AWG wire construction that allows for a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed.
The 10m cable offers a bandwidth of 10.8 Gbps with support for maximum resolutions up to WQXGA (2560×1600) and optional audio support. The cable is both HDCP and DPCP capable, which ensures that digitally protected content is displayed properly.
This 10-meter Active DisplayPort cable is backed by StarTech.com’s 2-year Warranty.
Please Note : This cable features unidirectional architecture which requires that the cable is installed in the correct direction. Please refer to the “source” and “display” labels on the DisplayPort connectors, in order to ensure that the display device (monitor, projector etc.) and the DisplayPort source are connected properly.
The StarTech.com Advantage
Additional information
| Weight | 0.47 lbs |
|---|---|
| Cable length | 10 m |
| Connector 1 | DisplayPort |
| Connector 2 | DisplayPort |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Product colour | Black |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Connector contacts plating | Nickel |
| Weight | 452 g |
| Quantity per pack | 1 pc(s) |
| Harmonized System (HS) code | 84733080 |
| Products per master (outer) case | 20 pc(s) |
| Maximum resolution | 2560 x 1600 pixels |
| DisplayPort version | 1.2 |
| HDCP | Yes |
| Latching connectors | Yes |
| AWG wire size | 32 |
| Multi-Stream Transport (MST) | Yes |
| Number of conductors | 19 |
| Operating temperature (T-T) | 0 – 45 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Package width | 255 mm |
| Package depth | 330 mm |
| Package height | 40 mm |
| Package weight | 466 g |
| Master (outer) case width | 334 mm |
| Master (outer) case length | 502 mm |
| Master (outer) case height | 239 mm |
| Cable rating | CMG (CM) |
| Jacket material | Polyvinyl chloride (PVC) |
| Compliance certificates | CE, RoHS |
| DisplayPort Content Protection (DPCP) | Yes |
| Bandwidth | 10800 MB/s |
| Magnetically shielded | Yes |
