StarTech.com 4 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III – 6 Gbps HDD
StarTech.com 4 Drive Bay Aluminum Trayless Hot Swap Mobile Rack Backplane with Fan & Lock for 3.5in SAS II / SATA III – 6 Gbps Hard Drive
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Connect and hot swap four 3.5in SATA III or SAS II hard drives to your computer system in three 5.25” bays, with support for transfer speeds up to 6 Gbps
The HSB4SATSASBA Removable 4-drive Backplane makes inserting and removing drives fast and easy, by turning three 5.25″ bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD).
For added versatility, the hot swap bay can interface with SATA I/II/III and SAS I/II hard drives — an ideal solution for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides drive cooling with a built-in fan and excellent heat dissipation with a vented aluminum enclosure.
The HSB4SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Additional information
| Weight | 1.6 lbs |
|---|---|
| Product colour | Black |
| Hot-swap | Yes |
| Number of fans | 1 fan(s) |
| Data transfer rate | 6 Gbit/s |
| LED indicators | Activity, Power |
| Key lock | Yes |
| Width | 145 mm |
| Depth | 197 mm |
| Height | 124 mm |
| Weight | 1.3 kg |
| Package width | 254 mm |
| Package depth | 164 mm |
| Package height | 180 mm |
| Package weight | 1.59 kg |
| Storage temperature (T-T) | -20 – 65 °C |
| Operating temperature (T-T) | 0 – 55 °C |
| Operating relative humidity (H-H) | 5 – 85% |
| Compliance certificates | RoHS |
| Products per master (outer) case | 6 pc(s) |
| Master (outer) case width | 385 mm |
| Master (outer) case length | 516 mm |
| Master (outer) case height | 281 mm |
| Material | Aluminium |
| Fan diameter | 7 cm |
| Cables included | SATA |
| Screws included | Yes |
| Harmonized System (HS) code | 84733080 |
| Certification | CE, FCC |
| Manual | Yes |
| External SATA ports quantity | 4 |
