StarTech.com 6ft (1.8m) Mini DisplayPort to DVI Cable – Mini DP to DVI Adapter Cable – 1080p Video – Passive mDP 1.2 to DVI-D S
StarTech.com 6ft (1.8m) Mini DisplayPort to DVI Cable – Mini DP to DVI Adapter Cable – 1080p Video – Passive mDP 1.2 to DVI-D Single Link – mDP or Thunderbolt 1/2 Mac/PC to DVI Monitor (MDP2DVIMM6B)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Connect a DVI display to a Mini DisplayPort-equipped PC or MAC® over a 6 foot distance – Black
The MDP2DVIMM6B Mini DisplayPort to DVI Adapter Cable lets you directly connect your Mini DP video source (such as any of your MacBook® or Microsoft® Surface™ Pro devices with mDP) to a DVI monitor or projector, eliminating the expense of having to upgrade to a Mini DisplayPort-capable monitor.
The adapter cable is 6 feet (1.8 m) in length, and features male-to-male connectors, allowing you to connect your Mini DisplayPort source directly to a DVI display with no additional cabling required.
Compatible with Intel® Thunderbolt™, when connected directly to a supporting DisplayPort over Thunderbolt I/O port, the adapter supports resolutions up to 1920×1200 (WUXGA).
MDP2DVIMM6B is a passive adapter that requires a dual-mode DisplayPort port (DisplayPort++), meaning that DVI and HDMI signals can also be passed through the port.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
Additional information
| Weight | 0.12 lbs |
|---|---|
| Cable length | 1.8 m |
| Connector 1 | Mini DisplayPort |
| Connector 2 | DVI-D |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| DisplayPort version | 1.2 |
| Maximum resolution | 1920 x 1200 pixels |
| Product colour | Black |
| Plug and Play | Yes |
| Compliance certificates | CE, RoHS |
| Quantity per pack | 1 pc(s) |
| Operating temperature (T-T) | 0 – 60 °C |
| Storage temperature (T-T) | -10 – 70 °C |
| Operating relative humidity (H-H) | 40 – 85% |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Supported video modes | 1080p |
| Weight | 101.3 g |
| Converter type | Passive |
| Package width | 160 mm |
| Package depth | 240 mm |
| Package height | 20 mm |
| Package weight | 125 g |
| Master (outer) case width | 420 mm |
| Master (outer) case length | 415 mm |
| Master (outer) case height | 435 mm |
| Products per master (outer) case | 150 pc(s) |
| Harmonized System (HS) code | 84733080 |
| Chipset | NXP – 3361 |
| Width | 40 mm |
| Depth | 1800 mm |
| Height | 15 mm |
| Dual Link DVI | No |
