StarTech.com MSA Uncoded SFP Module – 1000BASE-SX – 1GbE Multi Mode Fiber (MMF) Optic Transceiver – 1GE Gigabit Ethernet SFP –
StarTech.com MSA Uncoded Compatible SFP Module – 1000BASE-SX – 1GbE Multi Mode Fiber (MMF) Optic Transceiver – 1GE Gigabit Ethernet SFP – LC 550m – 850nm – DDM (SFPSXMM)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | TAA | Lifetime Warranty
The SFPSXMM is a TAA compliant MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 1000BASE-SX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 550 m (1804 ft) and delivers dependable 10 GbE connectivity over fiber cabling.
Technical Specifications:
• Wavelength: 850 nm
• Maximum Data Transfer Rate: 1.25 Gbps
• Type: Multi Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 550 m (1804 ft)
• MTBF: 78,286 hours
• Power Consumption: Less than 1 Watt
• DDM: No
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
Additional information
| Weight | 0.04 lbs |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP+ |
| Multi-mode fiber (MMF) supported | Yes |
| Fiber optic connector | LC |
| SFP transceiver standard | SX |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Networking standards | IEEE 802.3z |
| Duplex system | Full |
| Product colour | Silver |
| Hot-swap | Yes |
| Certification | CE, FCC, UL, TAA, REACH |
| Operating temperature (T-T) | 0 – 70 °C |
| Storage temperature (T-T) | -40 – 85 °C |
| Package width | 25 mm |
| Package depth | 115 mm |
| Package height | 65 mm |
| Package weight | 40 g |
| Dimensions (WxDxH) | 13 x 55 x 9 mm |
| Harmonized System (HS) code | 85369010 |
| Quantity per pack | 1 pc(s) |
| Fiber ethernet cabling technology | 1000BASE |
| Digital Diagnostics Monitoring (DDM) | No |
| Mean time between failures (MTBF) | 78286 h |
| Brand compatibility | MSA Compliant |
| Power consumption (typical) | 1 W |
| Compliance certificates | RoHS |
| Width | 13 mm |
| Depth | 55 mm |
| Height | 9 mm |
| Weight | 18 g |
| Master (outer) case width | 220 mm |
| Master (outer) case length | 560 mm |
| Master (outer) case height | 210 mm |
| Products per master (outer) case | 100 pc(s) |
| Operating relative humidity (H-H) | 5 – 95% |
