StarTech.com SATA Drive to mSATA Host Adapter for 2.5in / 3.5in SATA Drives
StarTech.com mSATA to SATA HDD / SSD Adapter – Mini SATA to SATA Converter Card – mSATA to SATA 2.5/3.5 Hard Drive Adapter Converter Card (MSAT2SAT3)
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Turn an mSATA host connection into a standard SATA port
The MSAT2SAT3 mSATA to SATA adapter enables you to connect a standard SATA drive to an available mSATA port.
The adapter improves system capacity by enabling an mSATA port to host a larger SATA hard drive (tested up to 4TB). For guaranteed compatibility and performance the adapter is compliant with SATA I/II/III revisions, allowing for transfer speeds up to 6Gb per second.
The MSAT2SAT3 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Additional information
| Weight | 0.02 lbs |
|---|---|
| Product colour | Green |
| Operating temperature (T-T) | 5 – 50 °C |
| Storage temperature (T-T) | -25 – 70 °C |
| Weight | 10 g |
| Host interface | mSATA |
| Output interface | SATA |
| Data transfer rate (max) | 6 Gbit/s |
| Compliance certificates | CE, RoHS |
| Depth | 51 mm |
| Internal | Yes |
| Width | 30 mm |
| Height | 8 mm |
| Harmonized System (HS) code | 84733020 |
| Operating relative humidity (H-H) | 20 – 80% |
| Storage relative humidity (H-H) | 15 – 90% |
| Package width | 125 mm |
| Package depth | 225 mm |
| Package height | 10 mm |
| Package weight | 15 g |
| Products per master (outer) case | 100 pc(s) |
| Master (outer) case width | 295 mm |
| Master (outer) case length | 690 mm |
| Master (outer) case height | 215 mm |
| User guide | Yes |
| SATA revision | 3.0 |
| Screws included | Yes |
