Description
Extend a VGA signal to a remote display using Cat5 cabling
The ST121UTPEP VGA Video Extender over Cat5 – Point to Point lets you connect a remote VGA display/projector up to 80m (250ft) away from the VGA signal source. The ST121UTPEP is a bundled kit that includes both a local and a remote unit providing a complete end to end solution for a single source/display connection, transmitting the source VGA signal over a standard Ethernet cable (Cat5 or better UTP cable, terminated with RJ45 connectors).
Offering convenient and cost-effective VGA distribution, the ST121UTPEP only requires one power adapter which can be installed at either the local or remote end of the connection, depending on what is most convenient for your application.
To ensure a tidy installation, the ST121UTPEP includes a mounting bracket for the receiver to help eliminate unnecessary cable tangles.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Additional information
| Weight | 0.8 lbs |
|---|---|
| Type | AV transmitter & receiver |
| Cable types supported | Cat5 |
| Maximum transfer distance | 80 m |
| Material | Aluminium |
| Product colour | Black |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| DC-in jack | Yes |
| Compliance certificates | RoHS |
| Maximum resolution | 1920 x 1200 pixels |
| Supported graphics resolutions | 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA) |
| Mounting brackets included | Yes |
| VGA (D-Sub) input ports | 1 |
| VGA (D-Sub) output ports | 1 |
| Operating voltage | 12 V |
| Weight | 263 g |
| Package width | 140 mm |
| Package depth | 315 mm |
| Package height | 60 mm |
| Package weight | 795 g |
| AC adapter included | Yes |
| Manual | Yes |
| Cables included | VGA |
| Certification | CE, FCC, REACH, TAA |
| Output current | 0.6 A |
| Width | 138 mm |
| Depth | 100 mm |
| Height | 25 mm |
| External power adapter | Yes |
| Included power plug types | AU, EU, NA, UK |
| Plug and Play | Yes |
| Daisy chain | No |
| Power plug type | Type M |
| Power consumption (typical) | 7.2 W |
