TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE 300 Mbit/s White Power over Ethernet (PoE)
560MHz CPU, MIPS 74Kc, 64MB DDR2 RAM, 8MB Flash, IPX5
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
TP-LINK’s 2.4GHz 300Mbps 9dBi Outdoor CPE, the CPE210 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE210 an ideal choice for both business and home users.
Enterprise Hardware
With Qualcomm Atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and PoE power supply, CPE210 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -40℃ (-40℉) to +70 ℃ (158℉).
Advanced Antenna System
Built-in High Gain Dual-Polarized Antenna
Dedicated metal reflector ensures higher gain
and lower noise interference
5km+ Wireless Data Transmission
Specially designed for outdoor uses, ideal for long distance wireless data transmission over 5km+, tested in the field.
TP-LINK MAXtream TDMA Technology
As network scale increases, wireless competition and collisions among CPEs and base stations will be so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user experience. To mitigate these effects, the CPE210 uses MAXtream TDMA Technology.
Pharos Control – Centralized Management System
CPE210 also comes equipped with centralized management software that helps users easily manage all the devices in their network from a single PC – Pharos Control. Functions like device discovery, status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.
PharOS
User-friendly web-based management system allows professionals to do more specific configurations.
Additional information
| Weight | 0.712 lbs |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | No |
| Maximum data transfer rate | 300 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Frequency band | 2.4 – 2.483 GHz |
| Bandwidth | 2.4 GHz |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| MAC address filtering | Yes |
| Web-based management | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Power over Ethernet (PoE) | Yes |
| Input current | 0.8 A |
| Power consumption (max) | 10.5 W |
| Placement | Wall |
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
| Antenna type | Internal |
| Antenna gain level (max) | 9 dBi |
| Width | 224 mm |
| Depth | 79 mm |
| Height | 60 mm |
| Mounting kit | Yes |
| Certification | – FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark- RoHS, IPX5 |
| Operating relative humidity (H-H) | 10 – 90% |
| Operating temperature (T-T) | -30 – 70 °C |
| Storage temperature (T-T) | -40 – 70 °C |
| Storage relative humidity (H-H) | 5 – 95% |
| Antennas quantity | 1 |
| Cables included | AC |
| Flash memory | 8 MB |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Antenna features | Integrated antenna |
| International Protection (IP) code | IPX5 |
| Management protocols | TDMA |
| Internal memory | 64 MB |
| Output voltage | 24 V |
| Output current | 1 A |
| Harmonized System (HS) code | 85176990 |
| Receiver sensitivity | 802.11b:11M: -95dBm, 5.5M: -96dBm, 2M: -96dBm, 1M: -96dBm-802.11g:54M: -79dBm, 48M: -80dBm, 36M: -84dBm, 6-24M: -88dBm802.11n:MCS15: -76dBm, MCS14: -78dBm, MCS13: -80dBm,MCS12: -84dBm, MCS11: -87dBm, |
| Compatible operating systems | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. |
| Management platform | Pharos Control |
| Built-in processor | Yes |
| Processor frequency | 560 MHz |
| Maximum outdoor range | 5000 m |
| Processor model | Qualcomm Atheros |
