TP-Link TL-SG116 network switch Unmanaged Gigabit Ethernet (10/100/1000) Black

In Stock

16-Port Gigabit Desktop Switch

  • We give you a dedicated account manager with every order.
  • We welcome single and bulk orders. Get fast delivery each time.
  • We can offer installation and configuration on orders.
  • We care, get great pricing and great customer service.
  • Any further questions, get in touch on 01933 837600.
SKU: TL-SG116
Brand:

Description

What This Product Does

The TP-Link 16-Port 10/100/1000Mbps Desktop Switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Plug and Play design, with no configuration required, makes the product easy to use. Moreover, TL-SG116 adopts lower power consumption design. With the innovative energy-efficient technology, the TL-SG116 can save power consumption, making it an eco-friendly solution for your home or office network.

Gigabit Switch

Featured with 16 10/100/1000Mbps ports, TL-SG116 greatly expands your network capacity, enabling instant large files transferring. So, power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly.

Go Green With Your Ethernet

You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG116 16-Port 10/100/1000Mbps Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

Traffic Optimization

802.1p and DSCP QoS enable smooth latency-sensitive traffic such as voice and video, and IGMP Snooping optimizes the Multicast data stream.

Easy to use

The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. Moreover, fanless design ensures quiet operation.

Additional information

Weight 1.36 lbs
Switch type

Unmanaged

Quality of Service (QoS) support

Yes

Basic switching RJ-45 Ethernet ports quantity

16

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Networking standards

IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

10G support

No

Full duplex

Yes

Auto MDI/MDI-X

Yes

MAC address table

8000 entries

Switching capacity

32 Gbit/s

Store-and-forward

Yes

Jumbo frames support

Yes

Jumbo frames

9000

Packet buffer memory

4.1 MB

Rack mounting

No

Product colour

Black

Housing material

Metal

LED indicators

Yes

DC input voltage

9 V

Input current

0.6 A

Power consumption (max)

9.3 W

Power over Ethernet (PoE)

No

Operating temperature (T-T)

0 – 40 °C

Storage temperature (T-T)

-40 – 70 °C

Operating relative humidity (H-H)

10 – 90%

Storage relative humidity (H-H)

5 – 90%

Width

286 mm

Depth

111.7 mm

Height

25.4 mm

Harmonized System (HS) code

85176990

Copper ethernet cabling technology

10BASE-T, 100BASE-TX, 1000BASE-T

Flow control support

Yes

Auto-negotiation

Yes

VLAN support

Yes

Virtual LAN features

Protocol-based VLAN, Tagged VLAN

IGMP snooping

Yes

Power supply included

Yes

Cables included

AC

Quick start guide

Yes

AC input voltage

220 V

AC input frequency

50 Hz

Loop protection

Yes

Port mirroring

Yes

Broadcast storm control

Yes

Number of VLANs

32

Forwarding rate

23.81 Mpps

Wall mountable

Yes

Cable length detection

Yes

Heat dissipation

31.68 BTU/h

Gigabit Ethernet (copper) ports quantity

16

Rate limiting

Yes

Number of queues

4

Cable types supported

Cat3, Cat4, Cat5, Cat5e, Cat6
