iiyama 23.8” Full HD In-cell PCAP 10pt interactive Touch Panel PC with Android OS, IPS panel technology and anti glare coatin
23.8” Full HD In-cell PCAP 10pt interactive Touch Panel PC with Android OS, IPS panel technology and anti glare coating
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The ProLite TW2424AS-W1 interactive Touchpanel-PC is a perfect choice for high-use environments. The IPS panel, integrated in a slim and elegant bezel, delivers both excellent colour performance with wide viewing angles and noticeably sharper images. The In-cell 10tp PCAP touch technology ensures a fluid and natural touch experience. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Thanks to the pre-installed Android 12 operating system, it is possible to easily customize the monitor by installing applications directly to it. In combination with the 32GB storage, Wi-Fi connection, LAN (RJ45) and Bluetooth connectors, it makes the monitor especially suited for POS systems or information points in retail shops to educate customers about your products, as well as virtually limitless smart home applications.
Additional information
| Weight | 6.13 lbs |
|---|---|
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 250 cd/m² |
| LED backlighting type | Direct-LED |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Active display area (W x H) | 527 x 296.5 mm |
| Panel life | 50000 h |
| Horizontal scan range | 31 – 83 kHz |
| HDMI ports quantity | 1 |
| USB port | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| HDMI input ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 10 W |
| Product design | Digital signage flat panel |
| Product colour | Black |
| Purpose | Commercial |
| Power consumption (typical) | 19 W |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Internal storage capacity | 32 GB |
| Operating system installed | Android |
| Display width | 549.5 mm |
| Display depth | 28 mm |
| Display height | 336 mm |
| Weight (with stand) | 4.23 kg |
| Package width | 580 mm |
| Package weight | 6.15 kg |
| Remote control included | Yes |
| Cables included | HDMI, Power, USB |
| HD type | 4K Ultra HD |
| Touchscreen | Yes |
| Native aspect ratio | 16:9 |
| Pixel pitch | 0.275 x 0.275 mm |
| USB 2.0 Type-B ports quantity | 2 |
| Placement supported | Indoor |
| HDCP | Yes |
| Power consumption (standby) | 0.5 W |
| Internal memory | 4 GB |
| Display weight | 4.23 kg |
| Width (with stand) | 549.5 mm |
| Depth (with stand) | 28 mm |
| Height (with stand) | 336 mm |
| Package depth | 580 mm |
| Package height | 375 mm |
| Panel type | IPS |
| Response time | 14 ms |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Operating hours (hours/days) | 24/7 |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
| Surface hardness | 3H |
| VGA (D-Sub) input ports | 1 |
| Anti-glare screen | Yes |
| Computer system | Yes |
| Built-in processor | Yes |
| Processor cores | 2 |
| Operating system version | 12 |
| Stylus pen | Yes |
| Number of stylus pens | 4 |
| Display number of colours | 16.7 million colours |
| Display diagonal (metric) | 60.5 cm |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Mean time between failures (MTBF) | 50000 h |
| Power consumption (off) | 0.3 W |
| Processor family | ARM Rockchip |
| Processor frequency | 1.8 GHz |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| On Screen Display (OSD) | Yes |
| Processor manufacturer | Rockchip |
| Processor model | RK3399 |
| Quick start guide | Yes |
| Plug and Play | Yes |
| Batteries included | Yes |
| OPS slot | 1 |
| Base colour | Black |
| Base material | Metal |
| Suitable for indoor use | Yes |
| Power supply type | External |
| Bluetooth Low Energy (BLE) | Yes |
| Built-in microphone | Yes |
| Viewable size, horizontal | 52.7 cm |
| Viewable size, vertical | 29.6 cm |
