Zyxel GS1100-24E Unmanaged Gigabit Ethernet (10/100/1000) Black
Unmanaged, 24x Gigabit Ethernet, 48 Gbps
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
Plug and play connectivity
Simply unbox the GS1100 unmanaged switch, you can enjoy instant plug-n-play Gigabit connectivity without any additional settings required with auto-negotiation and auto MDI/MDI-X. Supporting 802.1p prioritization and jumbo frame, the switch ensures smooth voice and video traffic for your office network.
Whisper quiet operation
The GS1100 Series has fanless design that ensures silent operation in small or quiet office environments. The GS1100-10HP PoE model is specifically designed with an external power adapter that eliminates the need for an additional fan to cool down the device, making it perfect for quiet PoE deployments.
Energy saving
The GS1100 features Energy Efficient Ethernet(IEEE 802.3az) which automatically detects network traffic and adjusts power consumption dynamically. Zyxel’s green features also adjust power consumption by detecting the link status and cable length reducing business operating expenses.
Support PoE+
The GS1100-10HP supports PoE+ (IEEE 802.3at) which provides a maximum of 30W per port, delivering fully automated support for powering compatible IP phones, video surveillance cameras or wireless access points.
Flexible choices for your office
The GS1100 Series switch offers multiple options including 8-port, 16-port, and 24-port for diversified office applications.
Additional information
| Weight | 2.14 lbs |
|---|---|
| Switch type | Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| MAC address table | 8000 entries |
| Switching capacity | 48 Gbit/s |
| Jumbo frames | 10000 |
| Packet buffer memory | 0.525 MB |
| Rack mounting | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Mean time between failures (MTBF) | 366919 h |
| Power consumption (max) | 13 W |
| Power over Ethernet (PoE) | No |
| Operating temperature (T-T) | 0 – 40 °C |
| Width | 267 mm |
| Depth | 162 mm |
| Height | 42 mm |
| Weight | 1.5 kg |
| Harmonized System (HS) code | 85176990 |
| Power supply included | Yes |
| Cables included | AC |
| Certification | LVD, BSMI, EMC Class A, CE, FCC, RCM, ICES-003, BSMI, RoHS, REACH |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Forwarding rate | 35.7 Mpps |
| Wall mountable | Yes |
| Fanless | Yes |
| Heat dissipation | 43.53 BTU/h |
| Rack mount kit | Yes |
