Zyxel XGS1930-28 Managed L3 Gigabit Ethernet (10/100/1000) Black
XGS1930-28 – 24-port GbE Smart Managed Switch with 4 SFP+ Uplink
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
The most affordable choice for 10G migration
The XGS1930 series, a new 10G uplink smart managed switch, comes with a stylish new look and enables cloud manageability with Zyxel NebulaFlexTM technology.
Built for convenience
This smart-looking switch features an intuitive design that simplifies daily network management for SMBs.
Manage it your way!
The XGS1930 series introduces Zyxel NebulaFlexTM, which allows you to easily switch between standalone mode and our license-free Nebula cloud management platform anytime with just a few simple clicks.
Don’t overspend to upgrade your wired network
With Gigabit connectivity plus four 10G uplinks, the XGS1930 series is ideal for those seeking to upgrade to an easier-to-manage network—and at an affordable price.
Whisper-quiet operation
Smart fan and fanless designs for silent operation in your workplace.
Power more devices more easily
– Provides 30W per port and a high power budget of 375W, ideal for denser PoE deployments.
– Default consumption mode boosts efficiency by delivering the actual power required.
User-friendly LED indicators
View real-time status instantly with cloud and PoE power-usage LED indicators.
Zyxel ONE Network
Use the complimentary ZON Utility to configure and discover switches, WLANs, and gateways in your network with one click.
Designed for the long haul
A web smart managed switch with an enterprise-grade hardware design. Built-in state-of-the-art hardware technology brings high quality and robustness to SMB networks.
Additional information
| Weight | 4.54 lbs |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| MAC address table | 16000 entries |
| Switching capacity | 128 Gbit/s |
| Packet buffer memory | 1.5 MB |
| Rack mounting | Yes |
| Product colour | Black |
| Mean time between failures (MTBF) | 1211024 h |
| Power consumption (max) | 24.6 W |
| Power over Ethernet (PoE) | No |
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating relative humidity (H-H) | 10 – 95% |
| Storage relative humidity (H-H) | 10 – 95% |
| Width | 441 mm |
| Depth | 270 mm |
| Height | 44 mm |
| Weight | 3.4 kg |
| Harmonized System (HS) code | 85176990 |
| Switch layer | L3 |
| Web-based management | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Flow control support | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN, Voice VLAN |
| DHCP features | DHCP client, DHCP relay, DHCPv6 relay |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| Electromagnetic compatibility | FCC 15 A, CE A, BSMI EMC |
| Cables included | AC |
| Package weight | 4.47 kg |
| Certification | RoHS |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Static route | Yes |
| Loop protection | Yes |
| Port mirroring | Yes |
| Broadcast storm control | Yes |
| Number of VLANs | 4000 |
| Forwarding rate | 95.2 Mpps |
| Password protection | Yes |
| Internal memory | 512 MB |
| Flash memory | 32 MB |
| Link aggregation | Yes |
| Package type | Box |
| Noise level | 0 dB |
| Heat dissipation | 83.886 BTU/h |
| Package width | 616 mm |
| Package depth | 355 mm |
| Package height | 107 mm |
| SFP+ module slots quantity | 4 |
| SSH/SSL support | Yes |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
| Multicast support | Yes |
| IP routing | Yes |
| Security algorithms | 802.1x RADIUS, HTTPS, SHA-2, SNMPv3, SSL/TLS |
| Rack mount kit | Yes |
| Routing entries | 32 |
