APC Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit
Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit
- We give you a dedicated account manager with every order.
- We welcome single and bulk orders. Get fast delivery each time.
- We can offer installation and configuration on orders.
- We care, get great pricing and great customer service.
- Any further questions, get in touch on 01933 837600.
Description
This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 1000VA double-conversion on-line 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. The SRV comes with IEC 320 C14 input and 3x IEC 320 C13 outlets. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The SRV UPS is compatible with replacement battery cartridge APCRBCV200. The UPS is compatible with SRVRK1 rail kit sold separately. The UPS and the built-in lead-acid battery has a 2-year warranty. Ideal for small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunication, and healthcare IT.
Additional information
| Weight | 14.04 lbs |
|---|---|
| Output power capacity | 1 kVA |
| Output power | 800 W |
| Input frequency | 40/70 Hz |
| Emergency Power Off (EPO) | No |
| Audible alarm(s) | Yes |
| Battery recharge time | 4 h |
| Product colour | Black |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -20 – 50 °C |
| Operating relative humidity (H-H) | 0 – 95% |
| Storage relative humidity (H-H) | 0 – 95% |
| Operating altitude | 0 – 3000 m |
| Non-operating altitude | 0 – 14763.6 m |
| Certification | CE, IEC 62040-1-1, IEC 62040-1-2REACH |
| Weight | 11 kg |
| Harmonized System (HS) code | 85078000 |
| Nominal input voltage | 230 V |
| Package weight | 13.1 kg |
| Input operation voltage (min) | 160 V |
| Input operation voltage (max) | 280 V |
| Form factor | Rackmount |
| Compliance certificates | RoHS |
| Width | 437 mm |
| Depth | 312 mm |
| Height | 86 mm |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Number of output phases | 1 |
| Efficiency | 88% |
| Crest factor | 3:1 |
| Noise level | 50 dB |
| Auto-restart | Yes |
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| AC outlets quantity | 3 AC outlet(s) |
| Serial interface | Yes |
| SmartSlot | Yes |
| Battery technology | Sealed Lead Acid (VRLA) |
| Automatic battery test | Yes |
| Rack capacity | 2U |
| Display type | LCD |
| LED indicators | Yes |
| Cables included | USB cable |
| Manual | Yes |
| Software CD | Yes |
| Package width | 455 mm |
| Package depth | 551 mm |
| Package height | 218 mm |
| Nominal output voltage | 230 V |
| Surge energy rating | 600 J |
| Serial ports quantity | 1 |
| Output frequency | 50/60 Hz |
| Output voltage regulation | 1% |
| Input power factor | 0.95 |
| ECO mode | Yes |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Number of input phases | 1 |
| USB port | Yes |
| USB port type | USB Type-B |
| Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| Output power factor | 0.8 |
| Transfer time (Line Mode to Battery Mode) | 0 ms |
| Socket circuit breaker | Yes |
| Maintenance-free | Yes |
